Buick Enclave 2026 Fuse Box Info

Passenger compartment fuse box location:

The instrument panel fuse box is inside the center console on the passenger side of the vehicle.

Engine compartment fuse box location:

Luggage compartment fuse box location:

The rear compartment fuse box may be located behind two trim panels on the driver side of the rear storage compartment.

Fuse Box Diagram | Layout

Passenger compartment fuse box:

Fuse/Relay N°	Functions
1	BLOWER MOTOR
2	SPARE
3	SCL – Steering Column Lock
4	SPARE
5	BCM 2 – Body Control Module 2
6	OHC – OnStar Hands Free Calling
7	STEERING WHEEL CONTROL
8	TELEMATICS
9	S658_A505/A15_BAT 1
10	RAIN SNR/UGDO – Rain Sensor/Universal Garage Door Opener SPARE
11	HVAC & TPIM_HUD– Heating, Ventilation, and Air Conditioning and Traction Power Inverter Module_Head Up Display
12	RC_E600
13	CGM & DLC – Central Gateway Module and Data Link Connector
14	EBCM & PCM – Electronic Brake Control Module and Power Control Module
15	AUX DISPLAY
16	APO_RR_CARGO – Auxiliary Power Outlet_Rear_Cargo
17	SDM_AOS Sensing Diagnostic Module_Automatic Occupant Sensor SPARE
18	LF & RF_A766_DR & CO DR_A765
19	ELM RC – Exterior Lighting Module Ride Control
20	VKM – Virtual Key Module SPARE
21	VCU_BATT 1 & 2 – Virtual Cockpit Unit Battery 1 and 2
22	SDM – Sensing Data Module
23	APO ROW 1 – Auxiliary Power Outlet Row 1
24	WCM – Wireless Charging Module
25	HVPO – High Voltage Power Outlet
26	SPARE
27	AUX
28	LRR – Long Range Radar
29	SRR – Short Range Radar
30	-
31	BCM 3 – Body Control Module 3
32	HSWM – Heated Steering Wheel Module
33	-
34	CPM – Column Position Module
35	AMPLIFIER
36	DC/DC BATT 2 – Direct Current/Direct Current Battery 2
37	BCM 4 – Body Control Module 4
38	AMPLIFIER 2
39	ELM 6 – Exterior Lighting Module 6
40	DCAC – Direct Current Alternating Current
CB01	-
CB02	APO – Auxiliary Power Outlet

Engine compartment fuse box:

Fuse/Relay N°	Functions
1	SPARE
2	SPARE
3	FRT_WIPER – Front Wiper
4	SPARE
5	SPARE
6	HDLP RT – Headlamp Right
7	RR_WIPER – Rear Wiper
8	SPARE
9	RR DEFOG – Rear Defog
10	ELM_4 – Exterior Lighting Module 4
11	HDLP LT – Headlamp Left
12	HORN
13	SPARE
14	SPARE
15	SPARE
16	RR_WPR_CTRL – Rear Wiper Control
17	RLY COIL GND – Relay Coil Ground
18	DC DC BATT1 – Direct Current Direct Current Battery 1
19	ELM7 – Exterior Lighting Module 7
20	SPARE
21	SPARE
22	ELM_5 – Exterior Lighting Module 5
23	WIPER_DE_ICE
24	EBCM1 – Electronic Brake Control Module 1
25	ELM_3 – Exterior Lighting Module 3
26	SPARE
27	TRLR_LTP_TRN_LT– Trailer Lamp Turn Left
28	TRLR_LTP_TRN_RT – Trailer Lamp Turn Right
29	WASH
30	AERO SHUTTER
31	SPARE
32	PCM – Power Control Module
33	SPARE
34	SPARE
35	PCM – Power Control Module
36	STRTR MTR – Starter Motor
37	AC CLUTCH GAS – Alternating Current Clutch Gas
38	SOL CP_TURBO BYPASS – Solenoid Turbo Bypass
39	COIL ODD
40	SPARE
41	SNSR MAF/IAT/H/P SNSR O2H MTR EVAPP
42	SPARE
43	SPARE
44	SPARE
45	SPARE
46	SPARE
47	SPARE
48	SPARE
49	SPARE
50	E-PHASER – Electronic Phaser
51	SPARE
52	PCM 2 – Power Control Module 2
53	SPARE
54	AIR_PUMP
55	SPARE
56	STRTR PINION – Starter Pinion
57	WATER PUMP
58	SERVICE FUSE
59	SERVICE FUSE
60	SERVICE FUSE
61	SERVICE FUSE
62	SERVICE FUSE
63	SERVICE FUSE

Luggage compartment fuse box:

Fuse/Relay N°	Functions
1	RR_BLOW – Rear Blow
2	DSP_CODR – Door Switch Panel_Code
3	TAILGATE
4	TRLR_BAT1 – Trailer Battery 1
5	ACP2 – AWD Control Processor 2
6	PWR_FOLD_SEAT_L_R – Power Fold Seat Left and Rear
7	DSP – Door Switch Panel
8	SPARE
9	LAMPS_RT – Right Lamps
10	SPARE
11	SPARE
12	SPARE
13	LAMPS_LT – Left Lamps
14	SP_DRVR
15	MSM_DRIVER – Memory Seat Module Driver
16	MTR PFTS_ROW2_L
17	FRT
18	SBP_CO_DRIVER
19	MTR PFTS_ROW2_R
20	SPARE
21	RFA – Remote Function Actuator
22	SPARE
23	SPARE
24	SPARE
25	SPARE
26	CANISTER
27	UPA – Universal Park Assist
28	RDCM – Right Door Control Module
29	SBZA – Side Blind Zone Assist
30	TRLR_PRK_LMP – Trailer Park Lamp
31	FCM – Front Camera Module
32	SPARE
33	ROW2_BAT1 – Second Row Battery 1
34	SPARE
35	SPARE
36	ROW2_BAT2 – Second Row Battery 2
37	SPARE
38	SPARE
39	SPARE
40	TRLR_BACK_UP – Trailer Backup Light
41	ELM 2 – Exterior Lighting Module 2
42	DSP – Door Switch Panel
43	POWER FOLD SEAT SW/N 3_ROW
44	OUT_OF_PARK_DISABLE
45	TRAILER_BRAKE
46	ACP3 – AWD Control Processor 3
47	FTZM – Fuel Tank Zone Module
48	SP_PASS
49	SPARE
50	ELM 1 – Exterior Lighting Module 1
51	FRT_BAT2 – Front Battery 2
52	SPARE
53	SPARE
54	ROW2_FOLD_RH – Second Row Right-hand Fold
55	ROW3
56	SUNROOF
57	RDCM – Right Door Control Module
