Acura TL 2004 Fuse Box Info
Passenger compartment fuse box location:
The interior fuse box is located on the driver’s lower left side.
Engine compartment fuse box location:
Fuse Box Diagram | Layout
Passenger compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| 1 | 15A | DBW |
| 2 | 15A | IGI Coil |
| 3 | - | Not Used |
| 4 | 15A | LAF |
| 5 | 20A | Radio |
| 6 | 7.5A | Interior Lights |
| 7 | 7.5A | Back Up |
| 8 | 20A | Door Lock |
| 9 | 15A | Front Accessory Socket |
| 10 | 7.5A | IGI OPDS |
| 11 | 30A | IGI Wiper |
| 12 | - | Not Used |
| 13 | 20A | Passenger’s Power Seat (Recline) |
| 14 | 20A | Driver’s Power Seat (Slide) |
| 15 | 20A | Seat Heater |
| 16 | 20A | Driver’s Power Seat (Recline) |
| 17 | 20A | Passenger’s Power Seat (Slide) |
| 18 | 15A | IGI ACG |
| 19 | 15A | IGI Fuel Pump |
| 20 | 7.5A | Washer |
| 21 | 7.5A | Meter |
| 22 | 10A | SRS |
| 23 | 7.5A | IGP |
| 24 | 20A | Rear Left Power Window |
| 25 | 20A | Rear Right Power Window |
| 26 | 20A | Front Right Power Window |
| 27 | 20A | Front Left Power Window |
| 28 | 20A | Moonroof |
| 29 | 7.5A | OP1 |
| 30 | 7.5A | HAC |
| 31 | 7.5A | OP2 |
| 32 | 7.5A | ACC |
| 33 | 7.5A | HAC OP |
Engine compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| 1 | 15A | Left Headlight Low Beam |
| 2 | 30A | Rear Defroster Coil |
| 3 | 7.5A | Left Headlight High Beam |
| 4 | 10A | Small Light |
| 5 | 7.5A | Right Headlight High Beam |
| 6 | 15A | Right Headlight Low Beam |
| 7 | 7.5A | Back Up |
| 8 | 15A | IGP |
| 9 | 30A | Condenser Fan |
| 10 |
20A 15A |
Front Fog Light*1 Daytime Running Light*2 |
| 11 | 30A | Radiator Fan Motor |
| 12 | 7.5A | MG Clutch Relay |
| 13 | 20A | Horn, Stop |
| 14 | 40A | Rear Defroster |
| 15 | 40A | Back UP, ACC |
| 16 | 15A | Hazard Warning |
| 17 | 30A | VSA Pump Motor Relay |
| 18 | 40A | VSA Fail Safe Relay |
| 19 | 40A | FI ECU |
| 20 | 40A | Power Seat |
| 21 | 40A | Heater Motor |
| 22 | 100A | Battery |
| 23 | 50A | IGI Main |
*1 U.S. models
*2 Canadian models
