Acura MDX 2015 Fuse Box Info
Passenger compartment fuse box location:
The interior fuse box A is located under the dashboard on the driver’s side. The interior fuse box B is on the lower side panel on the passenger’s side.
Engine compartment fuse box location:
Luggage compartment fuse box location:
The rear fuse box is located at the left side of cargo area.
Fuse Box Diagram | Layout
Passenger compartment fuse box A:
Fuse/Relay N° | Rating | Functions |
1 | 10A | Passenger’s Side Door Lock |
2 | 7.5A | Rear Passenger’s Side Door Lock |
3 | 7.5A | Driver’s Side Door Lock |
4 | 10A | Passenger’s Door Unlock |
5 | 7.5A | Rear Passenger’s Side Door Unlock |
6 | 7.5A | Driver’s Side Door Unlock |
7 | 20A | Door Lock Main |
8 | 10A | HAC OP |
9 | 20A | ETS TELE |
10 | 15A | IG1 RR Box |
11 | 7.5A | IG1 Meter |
12 | 20A | IG1 FR Box |
13 | 7.5A | ACC |
14 | - | - |
15 | 20A | Driver’s Power Seat Sliding |
16 | 20A | Moonroof |
17 | 20A | Rear Driver’s Side Power Window |
18 | 10A | SMART |
19 | 20A | Driver’s Power Window |
20 | - | - |
21 | 20A | Fuel Pump |
22 | 15A | AS Box |
23 | 7.5A | VSA |
24 | 7.5A | ACG AS |
25 | 7.5A | STRLD |
26 | 7.5A | IG2 HAC |
27 | 7.5A | IG2 DRL |
28 | 7.5A | ACC Key Lock |
29 | 7.5A | Driver Power Lumber |
30 | 7.5A | Interior Lights Cut |
31 | 20A | ETS TILT |
32 | 20A | Driver’s Power Seat Reclining |
33 | - | - |
34 | - | - |
Passenger compartment fuse box B:
Fuse/Relay N° | Rating | Functions |
1 | (30A) | Right e-pretensioner* |
2 | 20A | Rear Passenger’s Side Power Window |
3 | 20A | ACM |
4 | (15A) | Front DEF* |
5 | 20A | AVS/Seat Heaters |
6 | 20A | Front Passenger’s Power Window |
7 | 20A | Passenger’s Power Seat Sliding |
8 | 20A | Passenger’s Power Seat Reclining |
9 | (7.5A) | Passenger’s Lumber* |
10 | - | - |
11 | (10A) | HSW* |
12 | - | - |
13 | - | - |
14 | 20A | Rear Accessory Power Socket |
15 | 20A | Console Accessory Power Socket |
16 | - | - |
17 | - | - |
18 | 30A | Premium AMP |
19 | 10A | SRS1 |
20 | 7.5A | Passenger’s ECU |
21 | 7.5A | SVTM4 |
22 | - | - |
23 | - | - |
24 | 7.5A | IG1 OPDS |
25 | 7.5A | Illumination |
26 | (30A) | Left e-pretensioner* |
27 | 20A | Front Accessory Power Socket |
28 | (30A) | AC Inverter |
* Not available on all models
Engine compartment fuse box A:
Fuse/Relay N° | Rating | Functions |
1 | - | - |
2 | - | - |
3 | 15A | ACG FR |
4 | 15A | IG1 Washer |
5 | 7.5A | IG1 VBSOL |
6 | 7.5A | IG1 ECU FR |
7 | - | - |
8 | 15A | FI SUB |
9 | 15A | DBW |
10 | 15A | FI Main |
11 | 15A | IG Coil |
12 | 10A | DRL R |
13 | 10A | DRL L |
14 | 20A | INJ |
15 | 20A | Radio |
16 | 10A | Back Up |
17 | 7.5A | MG Clutch |
18 | (20A) | Front Fog* |
19 | - | - |
20 | 7.5A | Right Headlight High Beam |
21 | - | - |
22 | 10A | Small |
23 | - | - |
24 | 7.5A | Left Headlight High Beam |
25 | - | - |
26 | 10A | Right Headlight Low Beam |
27 | 10A | Left Headlight Low Beam |
28 | 7.5A | IGPS Oil LVL |
29 | 30A | Cooling Fan |
30 | 30A | Sub Fan |
31 | 30A | WIP Main |
* Not available on all models
Engine compartment fuse box B:
Fuse/Relay N° | Rating | Functions |
1 | 150A | Main Fuse |
2 |
40A 20A 30A 30A 40A 60A 60A 60A |
VSA MTR VSA FSR Stop/Horn/Hazard Rear Blower/BMS FI Main Rear F/B 2 AS F/B 2 EPS |
3 |
30A 30A 60A 50A 50A 60A 30A 50A |
H/L Washer IG1B Main R/B Main DR F/B 1 AS F/B 1 Rear F/B 1 IG1A Main DR F/B 2 |
4 | 30A | SVTM 4 |
5 | 40A | Front Blower |
6 | 40A | Rear Def |
7 | 40A | IG1 Main ST |
8 | 20A | Stop & Horn |
9 | 15A | Hazard |
10 | 7.5A | BMS |
11 | - | - |
Luggage compartment fuse box:
Fuse/Relay N° | Rating | Functions |
1 | 20A | Power Tailgate Closer |
2 | (20A) | Trailer Small Light* |
3 | - | - |
4 | 7.5A | Fuel Lid |
5 | 20A | Seat Slide |
6 | - | - |
7 | (20A) | Rear H/Seat* |
8 | - | - |
9 | (20A) | Trailer Charge* |
10 | (7.5A) | Trailer Back Light* |
11 | (7.5A) | Trailer Hazard* |
12 | 10A | Rear Wiper |
13 | 7.5A | ECU RR |
14 | - | - |
15 | - | - |
16 | - | - |
17 | (20A) | Trailer E-Brake* |
18 | 40A | Power Tailgate Motor |
* Not available on all models
