Alfa Romeo Giulia 2020 Fuse Box

Alfa Romeo Giulia 2020 Fuse Box Info



Passenger compartment fuse box location:

The fuse box is located on the right side below the foot board.



Engine compartment fuse box location:



Fuse Box Diagram | Layout



Passenger compartment fuse box:

Fuse/Relay N° Rating Functions
33 25A Front power window (driver’s side)
34 25A Front power window (passenger side)
36 15A Supply for Information and Entertainment system, Climate Control system, Alarm, Power door mirror folding, EOBD system, USB port
38 20A Safe Lock device (driver side door unlock – if equipped), doors unlock, central lock
43 20A Windshield washer pump
47 25A Rear left power window
48 25A Rear right power window
94 15A Heater rear window coil



Engine compartment fuse box:

Fuse/Relay N° Rating Functions
01 40A Tow hook module (TTM)
08 30A Hi-Fi system
17 7.5A KL15/a USB Recharge (C070)
21 10A I-Drive / USB / AUX port
22 20A KL15/a 12V Power outlet (R053)
