Volvo XC90 2016 Fuse Box Info
Passenger compartment fuse box location:
The fuse box in the passenger compartment is located behind the floor mat/side panel.
Engine compartment fuse box location:
Luggage compartment fuse box location:
Fuse Box Diagram | Layout
Passenger compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| 1 | - | - |
| 2 | 30A |
120-volt socket on the rear side of the tunnel console* 120-volt socket between the rear seatsA |
| 3 | - | - |
| 4 | 5A | Alarm system movement sensorB |
| 5 | 5A | Media player |
| 6 | 5A | Instrument panel |
| 7 | 5A | Center console buttons |
| 8 | 5A | Sun sensor |
| 9 | - | - |
| 10 | - | - |
| 11 | 5A | Steering wheel module |
| 12 | 5A | Module for start knob and parking brake |
| 13 | 15A | Heated steering wheel* module |
| 14 | - | - |
| 15 | - | - |
| 16 | - | - |
| 17 | - | - |
| 18 | 10A | Climate system control module |
| 19 | - | - |
| 20 | 10A | On-board diagnostics (OBDII) |
| 21 | 5A | Center display |
| 22 | 40A | Climate system blower module (front) |
| 23 | - | - |
| 24 | 7.5A | Instrument lighting; Courtesy lighting; Rearview mirror auto-dim function; Rain and light sensor; Rear tunnel console keypad*A ; Power front seats*; Power rear seatsA ; Display for rear seat convenience functionsA ; Rear seat massage functionA |
| 25 | 5A | Control module for driver support functions |
| 26 | 20A | Panorama roof and sun shade* |
| 27 | 5A | Head-up display* |
| 28 | 5A | Courtesy lighting |
| 29 | - | - |
| 30 | 5A | Ceiling console display (seat belt reminder, front passenger side airbag indicator) |
| 31 | - | - |
| 32 | 5A | Humidity sensor |
| 33 | 20A | Rear passenger-side door module |
| 34 | 10A | Fuses in the cargo compartment |
| 35 | 5A | Internet connection control module; Volvo On Call control module |
| 36 | 20A | Rear driver-side door module |
| 37 | 40A | Infotainment control module (amplifier) |
| 38 | 40A | Climate system blower module (rear) |
| 39 | 5A | Multi-band antenna module |
| 40 | 5A | Front seat massage function |
| 41 | - | - |
| 42 | 15A | Tailgate window wiper |
| 43 | 15A | Fuel pump control module |
| 44 | - | - |
| 45 | - | - |
| 46 | 15A | Driver side seat heating* |
| 47 | 15A | Passenger side seat heating* |
| 48 | 10A | Coolant pump |
| 49 | - | - |
| 50 | 20A | Front driver-side door module |
| 51 | 20A | Active chassis control module* |
| 52 | - | - |
| 53 | 10A | Sensus control module |
| 54 | - | - |
| 55 | - | - |
| 56 | 20A | Front passenger-side front door module |
| 57 | 5A | Display for rear seat convenience functionsA |
| 58 | - | - |
| 59 | 15A | Circuit breaker for fuses 53 and 58 |
* Option/accessory
A XC90 Excellence
B Certain markets only
Engine compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| 18 | - | - |
| 19 | - | - |
| 20 | - | - |
| 21 | - | - |
| 22 | - | - |
| 23 | 5A | Front USB socket* |
| 24 | 15A | 12-volt socket in the front tunnel console |
| 25 | 15A |
12-volt socket on the rear side of the tunnel consoleA 12-volt socket in the tunnel console between the rear seatsB |
| 26 | 15A |
12-volt socket in the cargo compartment USB sockets for iPad holdersB |
| 27 | - | - |
| 28 | - | - |
| 29 | - | - |
| 30 | - | - |
| 31 | Shunt | Heated windshield*, driver side |
| 32 | 40A | Heated windshield*, driver side |
| 33 | 25A | Headlight washers* |
| 34 | 25A | Windshield washer |
| 35 | - | - |
| 36 | 20A | Horn |
| 37 | 5A | Alarm siren* |
| 38 | 40A | Brake system control module (valves, parking brake) |
| 39 | 30A | Windshield wipers |
| 40 | 25A | Tailgate window washer |
| 41 | 40A | Heated windshield*, passenger side |
| 42 | - | - |
| 43 | 40A | Brake system control module (ABS pump) |
| 44 | - | - |
| 45 | Shunt | Heated windshield*, passenger side |
| 46 | 5A | Feed when ignition is switched on to: engine control module, transmission components, electrical power steering, central electrical module; Brake system control module |
| 47 |
- 5A |
- Exterior sound |
| 48 | 7.5A | Passenger side headlight |
| 49 | - | - |
| 50 | - | - |
| 51 |
5A - |
Battery connection control module - |
| 52 | 5A | Air bags; Occupant Weight Sensor (OWS) |
| 53 | 7.5A | Driver side headlight |
| 54 | 5A | Accelerator pedal sensor |
| 55 | 15A |
Transmission control module Gear selector control module |
| 56 | 5A | Engine control module |
| 57 | - | - |
| 58 | - | - |
| 59 | - | - |
| 60 | - | - |
| 61 | 20A | Engine control module; Turbocharger valve |
| 62 | 10A | Solenoids; Valves; Engine cooling system thermostat |
| 63 | 7.5A | Vacuum regulators; Valve |
| 64 | 5A | Spoiler shutter control module; Radiator shutter control module; Fuel leakage detection |
| 65 | - | - |
| 66 | 15A | Heated oxygen sensors (front and rear) |
| 67 | 15A | Oil pump solenoid; A/C magnetic coupling; heated oxygen sensor (center) |
| 68 | - | - |
| 69 | 20A | Engine control module |
| 70 | 15A | Ignition coil; Spark plugs |
| 71 | - | - |
| 72 | - | - |
| 73 | - | - |
| 74 | - | - |
| 75 | - | - |
| 76 | - | - |
| 77 | Shunt | Starter motor |
| 78 | 40A | Starter motor |
* Option/accessory
A Not XC90 Excellence
B XC90 Excellence
Luggage compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| 1 | 30A | Heated rear window |
| 2 | 20AA | Power rear seat (driver side)A |
| 3 | 40A | Pneumatic suspension* compressor |
| 4 | 30A | Rear auxiliary electric heater (passenger side) |
| 5 | - | - |
| 6 | 30A | Rear auxiliary electric heater (driver side)* |
| 7 | 20AA | Power rear seat (passenger side)A |
| 8 | - | - |
| 9 | 25A | Power tailgate* |
| 10 | 20A | Power front seat (passenger side)* module |
| 11 | 40A | Trailer hitch* control module |
| 12 | 40A | Seat belt tensioner module (passenger side) |
| 13 | 5A | Internal relay windings |
| 14 | - | - |
| 15 | 5A | Foot movement detection module for opening the power tailgate* |
| 16 | - | - |
| 17 | - | - |
| 18 | 25A | Trailer hitch* control module |
| 19 | 20A | Power front seat (driver seat* module) |
| 20 | 40A | Seat belt tensioner module (driver side) |
| 21 | 5A | Parking camera* |
| 22 | - | - |
| 23 | - | - |
| 24 | 5AA | Ionic air cleanerA |
| 25 | - | - |
| 26 | 5A | Airbag and seat belt tensioner modules |
| 27 | 10AA | Cooler; heated/cooled cup holder (rear)A |
| 28 | 15A | Heated rear seat (driver side)* |
| 29 | - | - |
| 30 | 5A | Blind Spot Information (BLIS)* |
| 31 | - | - |
| 32 | 5A | Seat belt tensioner modules |
| 33 | 5A | Emission system actuator |
| 34 | - | - |
| 35 | 15A | All Wheel Drive control module* |
| 36 | 15A | Heated rear seat (passenger side)* |
| 37 | - | - |
* Option/accessory
A XC90 Excellence
