Subaru Outback 2014 Fuse Box Info
Fuse box location:
The fuse box is located at the left side of the steering column at the bottom of the instrument panel.
Engine compartment fuse box:
Fuse Box Diagram | Layout
Passenger compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| 1 | 15A | Trailer hitch connector |
| 2 | 20A | Rear power window (left side) |
| 3 | 20A | Power window (driver’s side) |
| 4 | 7.5A | Navigation system, Front wiper deicer, Moonroof |
| 5 | 7.5A | Combination meter |
| 6 | 7.5A | Remote control rear view mirrors |
| 7 | 7.5A | Integrated unit |
| 8 | 15A | Stop light |
| 9 | 15A | Seat heater relay |
| 10 | 7.5A | Power supply (battery) |
| 11 | 7.5A | Turn signal unit |
| 12 | 15A | Integrated unit, Automatic transmission unit |
| 13 | 20A | Socket |
| 14 | 10A | Integrated unit |
| 15 | 20A | Rear power window (right side) |
| 16 | - | - |
| 17 | 15A | Front wiper deicer |
| 18 | 7.5A | Backup light |
| 19 | 7.5A | Electronic parking brake unit, Hill Holder system unit |
| 20 | 10A | Accessory power outlet |
| 21 | 7.5A | Starter relay |
| 22 | 15A | Air conditioner |
| 23 | - | - |
| 24 | 15A | Audio, Navigation system |
| 25 | 15A | SRS airbag system |
| 26 | 7.5A | Main fan |
| 27 | - | - |
| 28 | - | - |
| 29 | 20A | Power window (passenger’s side) |
| 30 | - | - |
| 31 | 7.5A | Automatic air conditioner unit |
| 32 | 7.5A | Steering lock |
| 33 | 7.5A | ABS/Vehicle dynamics control unit, Power steering |
Engine compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| 1 | 7.5A | CVT control unit |
| 2 | 7.5A | Horn (right side) |
| 3 | 7.5A | Horn (center) |
| 4 | 15A | Low beam headlight (right side) |
| 5 | 15A | Low beam headlight (left side) |
| 6 | 20A | Fuel pump |
| 7 | 10A | High beam headlight (left side) |
| 8 | 10A | High beam headlight (right side) |
| 9 | 20A | Continuously variable transmission control unit |
| 10 | 7.5A | Alternator |
| 11 | 10A | EyeSight system |
| 12 | 20A | Moonroof |
| 13 | 7.5A | Engine control unit |
| 14 | 15A | Engine control unit |
| 15 | 15A | Ignition coil |
| 16 | 15A | Engine control unit |
| 17 | 15A | Engine control unit |
| 18 | 10A | Automatic transmission control unit |
| 19 | 10A | Illumination |
| 20 | 10A | Rear combination light |
| 21 | 15A | Turn and hazard warning flasher (body control unit) |
| 22 | 20A | Door lock (body control unit) |
| 23 | 15A | Rear wiper, Rear washer |
| 24 | 10A | Front washer |
| 25 | 30A | Front wiper |
| 26 | 25A | Rear window defogger, Mirror heater, Front wiper deicer |
| 27 | 15A | Blower fan |
| 28 | 15A | Blower fan |
| 29 | 25A | Audio unit |
| 30 | 25A | Sub fan |
| 31 | 25A | Main fan |
| 32 | 30A | ABS/Vehicle dynamics control unit |
| 33 | 10A | Fog light (right side) |
| 34 | 10A | Fog light (left side) |
| 35 | 20A | Back-up (body control unit) |
| A | Main fuse |
