Seat Exeo 2011 Fuse Box Info
Passenger compartment fuse box location:
The instrument panel fuse box is located on the end of the instrument panel on the driver’s side of the vehicle.
Fuse Box Diagram | Layout
Passenger compartment fuse box::
| Fuse/Relay N° | Rating | Functions |
| 1 | 10A | Air conditioner |
| 2 | 5A | Footwell lamps |
| 3 | 5A | Heated washer jets |
| 4 | 5A | Radiator fan |
| 5 | 10A | Parking aid, automatic gearbox |
| 6 | 5A | Air conditioner (air purity sensor), pressure sensor |
| 7 | 10A | Electronic Stabilisation Program (ESP), brake light switch, clutch pedal switch, steering angle sensor |
| 8 | 5A | Telephone |
| 9 | - | Vacant |
| 10 | 5A | Adaptive headlights right |
| 11 | 5A | Airbag and disconnection of the front passenger airbag |
| 12 | 10A | Diagnostic socket |
| 13 | 10A | Steering column unit |
| 14 | 10A | Brake lights |
| 15 | 10A | instrument panel |
| 16 | 5A | Vacant |
| 17 | 10A | Tyre pressure control, rain/light sensor |
| 18 | 5A | Adaptive headlights left |
| 19 | - | Vacant |
| 20 | - | Vacant |
| 21 | - | Vacant |
| 22 | 15A | Driver's door / front passenger's door |
| 23 | 15A | Rear doors |
| 24 | 20A | Central electrics unit for convenience equipment |
| 25 | 30A | Heater blower |
| 26 | 30A | Rear window heater |
| 27 | 30A | Power socket for trailer (control unit) |
| 28 | 20A | Fuel pump, auxiliary pump for diesel |
| 29 | - | Vacant |
| 30 | 20A | Sliding/tilting sunroof |
| 31 | 15A | Diagnosis connection, automatic anti-dazzle interior mirror, reverse light, automatic gearbox |
| 32 | 15A | Towing socket |
| 33 | 20A | Lighter |
| 34 | 5A | Lambda probe heater |
| 35 | 20A | Luggage compartment power socket |
| 36 | 30A | Wiper system |
| 37 | 30A | Pump for windscreen washer and headlight washer system |
| 38 | 15A | Luggage compartment illumination, alarm |
| 39 | 20A | Radio, Amplifier |
| 40 | 25A | Horn |
| 41 | 30A | 230 volt socket |
| 42 | 25A | Electronic stabilisation programme (ESP) |
| 43 | 15A | Engine management |
| 44 | 35A | Seat heating |
