Peugeot 4008 2016 Fuse Box Info
Passenger compartment fuse box location:
The fuse box is located at the left side of the steering column at the bottom of the instrument panel, behind the cover.
Engine compartment fuse box location:
Fuse Box Diagram | Layout
Passenger compartment fuse box::
| Fuse/Relay N° | Rating | Functions |
| 1 | 30A | Cabin fan |
| 2 | 15A | Brake lamps, third brake lamp |
| 3 | 10A | Rear foglamps |
| 4 | 30A | Windscreen wiper, screenwash |
| 6 | 20A | Central locking, electric door mirrors |
| 7 | 15A | Audio equipment, telematics, USB unit, Bluetooth system |
| 8 | 7.5A | Remote control key, air conditioning control unit, instrument panel, electric windows, rain and sunshine sensors, alarm, switch panel, steering mounted controls |
| 9 | 15A | Instrument panel and interior lighting |
| 10 | 15A | Hazard warning lamps |
| 11 | 15A | Rear wiper |
| 12 | 7.5A | Instrument panel, multifunction screen, parking sensors, heated seats, heated rear screen, electric blind, automatic headlamp adjustment |
| 13 | 15A | Cigarette lighter, accessory socket |
| 15 | 20A | Electric blind |
| 16 | 10A | Door mirrors, audio equipment |
| 18 | 7.5A | Reversing lamps |
| 19 | 15A | Accessories socket |
| 20 | 30A | Electric window controls |
| 21 | 30A | Heated rear screen |
| 22 | 7.5A | Heated door mirrors |
| 24 | 25A | Driver's and passenger's electric seat |
| 25 | 30A | Heated seats |
Engine compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| 1 | 15A | Front foglamps |
| 4 | 10A | Horn |
| 5 | 7.5A | Alternator |
| 6 | 20A | Headlamp wash |
| 7 | 10A | Air conditioning |
| 9 | 20A | Alarm |
| 10 | 15A | Demisting, wipers |
| 11 | - | Not used |
| 12 | - | Not used |
| 13 | 10A | Daytime running lamps |
| 14 | 10A | Left-hand main beam headlamp |
| 15 | 10A | Right-hand main beam headlamp |
| 16 | 20A | Left-hand dipped beam headlamp (xenon) |
| 17 | 20A | Right-hand dipped beam headlamp (xenon) |
| 18 | 10A | Left-hand dipped beam headlamp (halogen), manual and automatic headlamp adjustment |
| 19 | 10A | Right-hand dipped beam headlamp (halogen) |
| 31 | 30A | Audio amplifier |
| 33 | 10A | Spare |
| 34 | 15A | Spare |
| 35 | 20A | Spare |
