Peugeot 5008 2015 Fuse Box Info
Passenger compartment fuse box location:
The fuse box is located at the left side of the steering column at the bottom of the instrument panel.
Engine compartment fuse box location:
Fuse Box Diagram | Layout
Passenger compartment fuse box::
| Fuse/Relay N° | Rating | Functions |
| 1 | 15A | Rear wiper |
| 2 | - | Not used |
| 3 | 5A | Airbag control unit |
| 4 | 10A | Electrochromatic rear view mirror, air conditioning, switching and protection unit, rear multimedia |
| 5 | 30A | Front one-touch electric windows |
| 6 | 30A | Rear one-touch electric windows |
| 7 | 5A | Front and rear courtesy lamps, map reading lamps, rear reading lamps, sun visor lighting, glove box lighting, centre armrest lighting, boot 12 V relay control |
| 8 | 20A | Audio equipment, audio/telephone, CD changer, multifunction scren, tyre under-inflation detection, alarm siren, alarm control unit, telematic unit |
| 9 | 30A | Front 12 V socket, cigarette lighter, rear 12 V socket |
| 10 | 15A | Steering mounted controls |
| 11 | 15A | Low current ignition switch |
| 12 | 15A | Trailer presence, rain/brightness sensor, supply for fuses F32, F34, F35 |
| 13 | 5A | Engine fusebox, airbag control unit |
| 14 | 15A | Instrument panel, instrument panel screen, supply for fuse F33 |
| 15 | 30A | Locking and deadlocking |
| 17 | 40A | Heated rear screen, supply for fuse F30 |
| 30 | 5A | Heated door mirrors |
| 31 | 30A | Boot 12 V socket |
| 32 | 5A | Electronic gearbox gear lever |
| 33 | 10A | Head-up display, Bluetooth system, air conditioning |
| 34 | 5A | Seat belt warning lamps display |
| 35 | 10A | Parking sensors, Hi-Fi amplifier authorisation |
| 36 | 10A | Trailer fuse box control unit, driver's door control pad |
| 37 | 20A | Hi-Fi amplifier |
| 38 | 30A | Driver's electric seat |
| 39 | 20A | Panoramic sunroof blind |
Engine compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| 2 | 15A | Horn |
| 3 | 10A | Front / rear wash-wipe |
| 4 | 10A | Daytime running lamps |
| 5 | 15A | Purge canister, turbine discharge and Turbo pressure regulation electrovalves (1.6 litre THP), oil vapour heater (1.6 litre THP), diesel heater (1.6 litre HDi) |
| 6 | 10A | Diagnostic socket, directional headlamps, particle emission filter pump (Diesel), Distance alert, mirror adjustment control |
| 7 | 10A | Power steering control unit, automatic gearbox, directional headlamps height adjustment motor |
| 8 | 20A | Starter motor control |
| 9 | 10A | Clutch and brake pedal switches |
| 11 | 40A | Air conditioning fan |
| 12 | 30A | Windscreen wipers slow/fast speed |
| 14 | 30A | Air pump |
| 15 | 10A | Right-hand main beam headlamp |
| 16 | 10A | Left-hand main beam headlamp |
| 17 | 15A | Left-hand dipped headlamp |
| 18 | 15A | Right-hand dipped headlamp |
The fuse block above the battery:
| Fuse N° | Rating | Functions |
| 2 | 5A | Dual function brake switch |
| 3 | 5A | Battery charge unit |
| 4 | 25A | ABS/DSC electrovalves |
| 6 | 15A | Electronic / automatic gearbox |
