Peugeot 5008 2014 Fuse Box

Peugeot 5008 2014 Fuse Box Info



Passenger compartment fuse box location:

The fuse box is located at the left side of the steering column at the bottom of the instrument panel.



Engine compartment fuse box location:





Fuse Box Diagram | Layout



Passenger compartment fuse box::

Fuse/Relay N° Rating Functions
1 15A Rear wiper
2 - Not used
3 5A Airbag control unit
4 10A Electrochromatic rear view mirror, air conditioning, switching and protection unit, rear multimedia
5 30A Front one-touch electric windows
6 30A Rear one-touch electric windows
7 5A Front and rear courtesy lamps, map reading lamps, rear reading lamps, sun visor lighting, glove box lighting, centre armrest lighting, boot 12 V relay control
8 20A Audio equipment, audio/telephone, CD changer, multifunction scren, tyre under-inflation detection, alarm siren, alarm control unit, telematic unit
9 30A Front 12 V socket, cigarette lighter, rear 12 V socket
10 15A Steering mounted controls
11 15A Low current ignition switch
12 15A Trailer presence, rain/brightness sensor, supply for fuses F32, F34, F35
13 5A Engine fusebox, airbag control unit
14 15A Instrument panel, instrument panel screen, supply for fuse F33
15 30A Locking and deadlocking
17 40A Heated rear screen, supply for fuse F30
30 5A Heated door mirrors
31 30A Boot 12 V socket
32 5A Electronic gearbox gear lever
33 10A Head-up display, Bluetooth system, air conditioning
34 5A Seat belt warning lamps display
35 10A Parking sensors, Hi-Fi amplifier authorisation
36 10A Trailer fuse box control unit, driver's door control pad
37 20A Hi-Fi amplifier
38 30A Driver's electric seat
39 20A Panoramic sunroof blind



Engine compartment fuse box:

Fuse/Relay N° Rating Functions
2 15A Horn
3 10A Front / rear wash-wipe
4 10A Daytime running lamps
5 15A Purge canister, turbine discharge and Turbo pressure regulation electrovalves (1.6 litre THP), oil vapour heater (1.6 litre THP), diesel heater (1.6 litre HDi)
6 10A Diagnostic socket, directional headlamps, particle emission filter pump (Diesel), Distance alert, mirror adjustment control
7 10A Power steering control unit, automatic gearbox, directional headlamps height adjustment motor
8 20A Starter motor control
9 10A Clutch and brake pedal switches
11 40A Air conditioning fan
12 30A Windscreen wipers slow/fast speed
14 30A Air pump
15 10A Right-hand main beam headlamp
16 10A Left-hand main beam headlamp
17 15A Left-hand dipped headlamp
18 15A Right-hand dipped headlamp



The fuse block above the battery:

Fuse N° Rating Functions
2 5A Dual function brake switch
3 5A Battery charge unit
4 25A ABS/DSC electrovalves
6 15A Electronic / automatic gearbox
