Mazda6 2009 Fuse Box Info
Fuse box location:
The fuse box is on the vehicle's left side.
Engine compartment fuse box:
Fuse arrangement in engine compartment.
Fuse Box Diagram | Layout
Passenger compartment fuse box:
Fuse | Rating | Functions |
1. P.WIND | 30A | Power window |
2. METER IG | 15A | For protection of various circuits |
3. ILLUMI | 7.5A | BCM, Illumination |
4. MIRROR | 5A | Power control mirror |
5. SAS | 5A | Air bag, ABS |
6. - | - | - |
7. INT, LOCK/SHIFT | 5A | AT shift* |
8. - | - | - |
9. HEGO | 5A | Power control mirror |
10. A/C | 10A | Air conditioner |
11. P.OUTLET/CIGAR | 15A | Lighter* |
12. D.LOOK | 25A | BCM, Door lock motor |
13. ENGINE IG | 15A | Engine control system |
14. WIPER | 25A | Windshield wiper and washer |
15. ROOM | 15A | Interior lights |
16. SPARE | - | - |
17. SPARE | - | - |
18. SPARE | - | - |
*Some models
Engine compartment fuse box:
Fuse | Rating | Functions |
1. M.DEF | 10A | Mirror defroster* |
2. ST SIG | 5A | Starter sig |
3. ABS SOL | 30A | ABS, DSC* |
4. P.WIND (P) | 25A | Power window |
5. P.SEAT (P) | 30A | Power seat* |
6. SUN ROOF | 15A | Moonroof* |
7. TAIL | 15A | BCM, Tail lamp |
8. P.OUTLET (R) | 15A | Accessory sockets |
9. AUDIO | 30A | Audio system (Bose® Sound System-equipped model) |
10. ABS MOTOR | 60A | ABS, DSC* |
11. P.WIND (D) | 40A | Power window |
12. DEFOG | 40A | Rear window defroster |
13. SEAT HEAT | 20A | Seat heat |
14. A/C | 10A | Air conditioner |
15. FOG | 15A | Fog lights* |
16. BLOWER 2 | 15A | Blower motor |
17. FAN | 60A | Cooling fan |
18. P.SEAT (D) | 30A | Power seat* |
19. BTN | 30A | For protection of various circuits |
20. IG KEY2 | 40A | Starting system |
21. BLOWER | 40A | Blower motor |
22. FUEL PUMP | 25A | Fuel pump |
23. ENGINE2 | 15A | Engine control system |
24. EGI INJ | 15A | Injector |
25. PCM | 10A | Engine control system |
26. ENGINE |
10A*1 20A*2 |
Engine control system |
27. IG | 20A | For protection of various circuits |
28. TCM | 20A | TCM* |
29. ESCL | 10A | Electronic steering lock |
30. IG KEY1 | 40A | For protection of various circuits |
31. MAIN | 125A | For protection of all circuits |
32. DRL | 20A | DRL* |
33. HAZARD | 10A | Hazard warning flashers |
34. ENG+B | 10A | PCM |
35. STOP | 10A | Brake lights |
36. HORN | 15A | Horn |
37. HEAD HI RH | 15A | Headlight-high beam (Right) |
38. HEAD LO RH | 10A | Headlight-low beam (Right) |
39. HEAD HI LH | 15A | Headlight-high beam (Left) |
40. HEAD LO LH | 10A | Headlight-low beam (Left) |
*1 2.5-liter engine
*2 3.7-liter engine
*Some models
