Maserati GranCabrio 2020 Fuse Box

Maserati GranCabrio 2020 Fuse Box Info



Passenger compartment fuse box location:

The fuse box is located at the left side of the steering column at the bottom of the instrument panel, behind the cover.



Engine compartment fuse box location:



Luggage compartment fuse box location:





Fuse Box Diagram | Layout



Passenger compartment fuse box:

Fuse/Relay N° Rating Functions
12 15A Right-hand low beam
13 15A Left-hand low beam
31 7.5A
A/C unit, NBC (Body Computer Node), high beam relay
32 10A Domelights, step lights, CAV, driver and passenger-side footwell lights, outside mirror light
33 30A Driver’s seat (movement)
34 30A Passenger’s seat (movement)
35 7.5A ACC, FN and LF relay coil
36 10A NQS
37 10A NQS (Instrument Panel Node), CPP, CPD
38 15A Rear lid lock
39 15A NIM (Inside Roof Node), NCL (Air conditioning and heating system node), OBD socket, CSA (Alarm system siren ECU), CAV (Motion sensing alarm ECU), radio, NAVTRAK
40 30A Heated rear window
41 15A Not used
42 7.5A NCL and windshield wiper controls
43 30A Windshield wiper/washer (Connected Devices Relay INT/A)
44 20A Front and rear power socket (INT/A device relay) front seat heating (passenger side)
45 25A Not used
46 20A NPG/NPP Locks
47 30A NPG (Driver’s door node)
48 30A NPP (Passenger’s door node)
49 7.5A NVO (Steering wheel node), CSG (Power steering ECU), CSP (Twilight/rain sensor ECU), NIM (Inside Roof Node), NCL, Radio, CEM, CRP, domelight molding, NAVTRAK
50 7.5A Airbag system
51 7.5A NCA (Automatic Gearbox Node)
52 15A Front seat heating (driver side) (INT/A device relay)
53 10A Rear fog lights




Engine compartment fuse box:

Fuse/Relay N° Rating Functions
01 60A Fan 1 relay
02 30A ABS valves
03 20A T03 spot lights relay
04 40A ABS cylinder
05 40A A.C. Node
06 60A Fan 2 relay
07 30A T07 I.E. main relay
08 7.5A T08 - Air conditioner compressor relay
09 7.5A T05 stop light control relay
10 15A T06 horn relay
11 10A LH high-beam
14 7.5A Third Stop
15 15A Alternator sensing
16 10A LH spot light
17 10A RH high-beam
18 7.5A I.E. bank
19 15A T02 DRL lights relay
20 10A T17 Key-Lock solenoid relay
21 - Not used
22 - Not used
23 10A ABS electronics
24 10A RH spot light
30 30A T20 ignition relay
81 50A CPL2
82 - Not used
83 50A Air pump relay
84 20A Ignition switch
85 30A Headlight washers
87 - Not used
88 15A Main injector/coil relay - cylinders 1-4
89 15A Main injector/coil relay - cylinders 5-8
90 15A Main I.E. relay, secondary connected devices
91 10A Main relay, I.E. ECU
92 15A Main relay, oxygen sensors
93 7.5A Not used
94 7.5A NCS
95 7.5A CSG
96 7.5A Alternator
97 10A I.E. ECU
98 - Not used
99 - Not used
100 - Not used
101 - Not used
102 - Not used
103 - Not used
104 - Not used
105 - Not used
106 - Not used
107 - Not used



Luggage compartment fuse box:

Fuse/Relay N° Rating Functions
54 30A HI-Fi amplifier
55 7.5A Lights
56 10A +30 NAG, NAVTRAK, Harman tuner, MTC+ (Japan)
57 - Not used
58 7.5A Reverse
59 15A Fuel tank door powering from T22
60 7.5A NSP
61 20A Rear RH ACE
62 20A NCA
63 15A +30 battery charge
64 - Not used
65 20A Rear LH ACE
66 20A Fuel pumps
67 - Not used
68 - Not used
69 - Not used
77 - Not used
78 20A Power socket
79 - Not used
80 25A Bass box
108 40A +30 NCP hydraulic pump
109 40A +30 NCP ECU/front latch
110 - Not used
111 - Not used
112 - Not used
113 - Not used
