Honda Ridgeline 2013 Fuse Box Info
Passenger compartment fuse box location:
The interior fuse box is on the driver’s lower left side.
Engine compartment fuse box location:
The primary under-hood fuse box is on the passenger’s side. The secondary fuse box is next to the brake fluid reservoir.
Fuse Box Diagram | Layout
Passenger compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| 1 | 7.5A | Bed Lights |
| 2 | 15A | IG Coil |
| 3 | 10A | Daytime Running Light |
| 4 | 15A | LAF |
| 5 | 20A | Radio |
| 6 | 10A | Interior Lights |
| 7 | 7.5A | Back Up |
| 8 | 20A | Door Lock |
| 9 | 10A | Front Accessory Socket |
| 10 | 7.5A | IG OPDS |
| 11 | 30A | IG Wiper |
| 12 | - | Not Used |
| 13 | (10A) | Driver’s Power Seat Lumbar* |
| 14 | (20A) | Driver’s Power Seat Sliding* |
| 15 | - | Not Used |
| 16 | (20A) | Driver’s Power Seat Reclining* |
| 17 | - | Not Used |
| 18 | 15A | IG ACG |
| 19 | 15A | IG Fuel Pump |
| 20 | 7.5A | IG Washer |
| 21 | 7.5A | IG Meter |
| 22 | 10A | IG SRS |
| 23 | 7.5A | IGP |
| 24 | 20A | Left Rear Window |
| 25 | 20A | Right Rear Window |
| 26 | 20A | Passenger’s Window |
| 27 | 20A | Back Window |
| 28 | 20A | Driver’s Window |
| 29 | 7.5A | VBSOL2 |
| 30 | 7.5A | IG HAC |
| 31 | 7.5A | IG VSA/ABS |
| 32 | 7.5A | ACC |
| 33 | (7.5A) | Not Used |
| Upper Area | ||
| 1 | 7.5A | STS |
* If equipped
Engine compartment fuse box (Primary):
| Fuse/Relay N° | Rating | Functions |
| 1 | 10A | Left Headlight Low Beam |
| 2 | - | Not Used |
| 3 | 10A | Left Headlight High Beam |
| 4 | 15A | Small Lights |
| 5 | 10A | Right Headlight High Beam |
| 6 | 10A | Right Headlight Low Beam |
| 7 | 7.5A | Back Up |
| 8 | 15A | FI ECU (PCM) |
| 9 | 15A | DBW |
| 10 | 20A | Front Fog Light* |
| 11 | 15A | Heated Seat* |
| 12 | 7.5A | MG Clutch |
| 13 | 20A | Horn, Stop |
| 14 | 20A | Defroster |
| 15 | 40A | Back Up, ACC |
| 16 | 15A | Hazard |
| 17 | 40A | Option 1 |
| 18 | 20A | AC Inverter* |
| 19 | 30A | Cooling Fan |
| 20 | 30A | Condenser Fan |
| 21 | 40A | Heater Motor |
| 22 |
40A 120A |
Seat Battery |
| 23 |
60A 50A |
+B IGI Main Power Window |
| 24-28 | - | Spare Fuses |
* If equipped
Engine compartment fuse box (Secondary):
| Fuse/Relay N° | Rating | Functions |
| 1 | (7.5A) | Back Light* |
| 2 | 20A | VSA FSR |
| 3 | 40A | VSA MTR |
| 4 | 20A | VTM-4 |
| 5 | 15A | Front Accessory Sockets |
| 6 | (20A) | Electric Brake* |
| 7 | (20A) | Small Lights* |
| 8 | (7.5A) | Stop/Turn Lights* |
| 9 | (20A) | Charge* |
| 10 | 7.5A | TPMS |
| 11 | (20A) | Moonroof* |
* If equipped
