Honda CR-V 2011 Fuse Box Info
Passenger compartment fuse box location:
The interior fuse box is located under the dashboard on the driver’s side.
Engine compartment fuse box location:
Fuse Box Diagram | Layout
Passenger compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| 1 | 7.5A | Power Window Relay |
| 2 | 15A | Fuel Pump |
| 3 | 10A | ACG |
| 4 | 7.5A | ABS/VSA |
| 5 | (15A) | Heated Seats* |
| 6 | - | - |
| 7 | - | Not Used |
| 8 | 10A | Rear Wiper |
| 9 | 7.5A | ODS (Ocupant Detection System) |
| 10 | 7.5A | Meter |
| 11 | 10A | SRS |
| 12 | 10A | Right Headlight High Beam |
| 13 | 10A | Left Headlight High Beam |
| 14 | 7.5A | Small Light (Interior) |
| 15 | 7.5A | Small Light (Exterior) |
| 16 | 10A | Right Headlight Low Beam |
| 17 | 10A | Left Headlight Low Beam |
| 18 | 20A | Main Headlight High Beam |
| 19 | 15A | Small Lights MAIN |
| 20 | 7.5A | TPMS |
| 21 | 20A | Headlight Low Beam |
| 22 | - | Not used |
| 23 | - | Not used |
| 24 | (20A) | Moonroof* |
| 25 | 20A | Door Lock |
| 26 | 20A | Front Left Power Window |
| 27 | - | - |
| 28 | 15A | Rear Accessory Power Socket |
| 29 | 15A | Front Accessory Power Socket |
| 30 | 20A | Front Right Power Window |
| 31 | (15A) | Accessory Power Socket* (in the Console Compartment/ on the Center Table) |
| 32 | 20A | Rear Right Power Window |
| 33 | 20A | Rear Left power window |
| 34 | 7.5A | ACC Radio |
| 35 | 7.5A | ACC Key lock |
| 36 | 10A | HAC |
| 37 | 7.5A | Daytime Running Lights |
| 38 | 30A | Front Wiper |
* If equipped
Passenger compartment fuse box (Auxiliary fuse box):
| Fuse/Relay N° | Rating | Functions |
| A | 10A | VB SOL |
| B | - | - |
The auxiliary fuse box is located next to the interior fuse box.
Engine compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| 1 |
100A - |
Battery Not Used |
| 2 |
80A 50A |
Option Main Ignition Switch Main |
| 3 |
20A 40A |
ABS/VSA FSR ABS/VSA Motor |
| 4 |
50A 40A |
Headlight Main Power Window Main |
| 5 | - | Not Used |
| 6 | 20A | Sub Fan Motor |
| 7 | 20A | Main Fan Motor |
| 8 | 30A | Rear Defogger |
| 9 | 40A | Blower |
| 10 | 15A | Hazard |
| 11 | 15A | LAF |
| 12 | 15A | Stop and Horn |
| 13 | (20A) | Power Seat DR RR HI/ Reclining* |
| 14 | (20A) | Power Seat DR FR HI/Sliding* |
| 15 | 7.5A | IGPS OIL LEVEL |
| 16 | - | Not Used |
| 17 | (15A) | High Power Sound* / Windshield Defroster |
| 18 | 15A | IG Coil |
| 19 | 15A | FI Main |
| 20 | 7.5A | MG Clutch |
| 21 | 15A | DBW |
| 22 | 7.5A | Interior Light |
| 23 | 10A | Back Up |
* If equipped
