Dodge Caliber 2010 Fuse Box Info
Engine compartment fuse box location:
Fuse Box Diagram | Layout
Engine compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| 1 | - | Empty |
| 2 | 15A | AWD/4WD ECU Feed |
| 3 | 10A | CHMSL Brake Switch Feed |
| 4 | 10A | Ignition Switch Feed/OCM |
| 5 | 20A | Trailer Tow |
| 6 | 10A | IOD Sw/Pwr Mir/Ocm Steering Cntrl Sdar/Hands Free Phone |
| 7 | 30A | IOD Sense1 |
| 8 | 30A | IOD Sense2 |
| 9 | 40A | Power Seats |
| 10 | 20A | CCN Power Locks/Interior Lighting |
| 11 | 15A | Power Outlet |
| 12 | 20A | Ign Run/Acc Inverter |
| 13 | 20A | Pwr Run/Acc Outlet RR/Dome Lamp/Cigar Lighter |
| 14 | 10A | IOD CCN |
| 15 | 40A | RAD Fan Relay Battery Feed |
| 16 | 15A | IGN Run/Acc Dome Lamp/Sunroof/Rear Wiper Motor/ACC Inverter |
| 17 | 10A | IOD Feed Mod-Wcm |
| 18 | 40A | ASD Relay Contact PWR Feed |
| 19 | 20A | PWR Amp 1 & Amp 2 Feed |
| 20 | 15A | IOD Feed Radio |
| 21 | 10A | IOD Feed Intrus Mod/Siren (If Equipped) |
| 22 | 10A | IGN RUN Heat/AC/Compass Sensor |
| 23 | 15A | ENG ASD Relay Feed 3 |
| 24 | 25A | PWR Sunroof Feed |
| 25 | 10A | Heated Mirror (If Equipped) |
| 26 | 15A | ENG ASD Relay Feed 2 |
| 27 | 10A | IGN RUN Only ORC Feed |
| 28 | 10A | IGN RUN ORC/OCM Feed |
| 29 | - | Hot Car (No Fuse Required) |
| 30 | 20A | Heated Seat (If Equipped) |
| 31 | 10A | Headlamp Washer Relay Control (If Equipped) |
| 32 | 30A | ENG ASD Control Feed 1 |
| 33 | 10A | ABS MOD/J1962 Conn/PCM |
| 34 | 30A | ABS Valve Feed |
| 35 | 40A | ABS Pump Feed |
| 36 | 30A | Headlamp/Washer Control/Smart Glass (If Equipped) |
| 37 | 25A | Diesel Fuel Heater — If Equipped |
