Chevrolet Suburban 2017 Fuse Box

Chevrolet Suburban 2017 Fuse Box Info



Passenger compartment fuse box location:

The left instrument panel fuse box is located on the driver side edge of the instrument panel.

The right instrument panel fuse box is located on the passenger side edge of the instrument panel.



Engine compartment fuse box location:





Luggage compartment fuse box location:





Fuse Box Diagram | Layout



Passenger compartment fuse box (Left):

Fuse/Relay N° Functions
1 Not Used
2 Not Used
3 Not Used
4 Accessory Power Outlet 1
5 Retained Accessory Power
6 APO/BATT
7 Universal Garage Door Opener/Interior Rear View Mirror
8 SEO Retained Accessory Power
9 Not Used
10 Body Control Module 3
11 Body Control Module 5
12 Steering Wheel Controls Backlighting
13 Not Used
14 Not Used
15 Not Used
16 Discrete Logic Ignition Sensor
17 Video processing module
18 Mirror Window Module
19 Body Control Module 1
20 Front Bolster (if equipped)
21 Not Used
22 Not Used
23 Not Used
24 HVAC/Ignition
25 Instrument Cluster Ignition/Sensing Diagnostic Module Ignition
26 Tilt Column/SEO, Tilt Column Lock 1/SEO
27 Data Link Connector/ Driver Seat Module
28 Passive Entry/Passive Start/Heater, Ventilation and Air Conditioning Battery
29 Content theft deterrent
30 Not Used
31 Not Used
32 Not Used
33 SEO/Automatic Level Control
34 Park Enable Electric Adjustable Pedal (if equipped)
35 Not Used
36 Miscellaneous R/C
37 Heated Steering Wheel
38 Steering Column Lock 2 (if equipped)
39 Instrument Cluster Battery
40 Not Used
41 Not Used
42 Euro Trailer (if equipped)
43 Left Doors
44 Driver Power Seat
45 Not Used
46 Right heated, cooled, or ventilated seat (if equipped)
47 Left heated, cooled, or ventilated seat (if equipped)
48 Not Used
49 Not Used
50 Accessory Power Outlet 2
51 Not Used
52 Retained Accessory Power/Accessory Relay
53 Run/Crank Relay
54 Not Used
55 Not Used
56 Not Used





Passenger compartment fuse box (Right):

Fuse/Relay N° Functions
1 Not Used
2 Not Used
3 Not Used
4 Accessory Power Outlet 4
5 Not Used
6 Not Used
7 Not Used
8 Glove Box
9 Not Used
10 Not Used
11 Not Used
12 Steering Wheel Controls
13 Body Control Module 8
14 Not Used
15 Not Used
16 Not Used
17 Not Used
18 Not Used
19 Body Control Module 4
20 Rear Seat Entertainment
21 Sunroof
22 Not Used
23 Not Used
24 Not Used
25 Not Used
26 Infotainment/Airbag
27 –/RF window switch/ Rain sensor
28 Obstacle detection/USB
29 Radio
30 Not Used
31 Not Used
32 Not Used
33 Not Used
34 Not Used
35 Not Used
36 Special equipment option B2
37 Special equipment option
38 Body Control Module 2
39 A/C Inverter
40 Not Used
41 Not Used
42 Not Used
43 Not Used
44 Right Door Window Motor
45 Front Blower
46 Body Control Module 6
47 Body Control Module 7
48 Amplifier
49 Right Front Seat
50 Accessory Power Outlet 3
51 Not Used
52 Retained accessory power relay
53 Not Used
54 Not Used
55 Not Used
56 Not Used





Engine compartment fuse box:

Fuse/Relay N° Functions
1 Electric Running Boards
2 Antilock Brake System Pump
3 Interior BEC LT1
4 Passenger motorized safety belt
5 Suspension leveling compressor
6 4WD Transfer Case Electronic Control
7 -
8 -
9 -
10 Electric Parking Brake
11 -
12 -
13 Interior BEC LT2
14 Rear BEC 1
15 -
16 -
17 Driver motorized safety belt
18 -
19 -
20 -
21 ALC Exhaust Solenoid
23 Integrated Chassis Control Module
24 Real Time Dampening
25 Fuel Pump Power Module
26 –/Battery regulated voltage control
27 -
28 Upfitter 2
29 Upfitter 2 Relay
30 Wiper
31 TIM
32 -
33 -
34 Reverse lamps
35 Antilock Brake System Valve
36 Trailer Brakes
37 Upfitter 3 Relay
38 -
39 Right trailer stoplamp/Turn signal lamp
40 Left trailer stoplamp/turn signal lamp
41 Trailer parking lamps
42 Right Parking Lamps
43 Left Parking Lamps
44 Upfitter 3
45 Automatic Level Control Run/Crank
46 -
47 Upfitter 4
48 Upfitter 4 Relay
49 Reverse Lamps
50 -
51 Parking Lamp Relay
52 -
53 -
54 -
55 -
56 -
57 -
58 -
59 Euro Trailer
60 Air Conditioning Control
61 -
62 -
63 Upfitter 1
64 -
65 -
66 -
67 Trailer Battery
68 -
69 RC Upfitter 3 and 4
70 VBAT Upfitter 3 and 4
71 -
72 Upfitter 1 Relay
73 -
74 Engine Control Module Ignition
75 Miscellaneous Ignition Spare
76 Transmission Ignition
77 RC Upfitter 1 and 2
78 VBAT Upfitter 1 and 2
79 -
80 -
81 -
82 -
83 Euro Trailer RC
84 Run/Crank Relay
85 -
86 -
87 Engine
88 Injector A – Odd
89 Injector B – Even
90 O2 sensor B
91 Throttle Control
92 Engine Control Module Relay
93 Horn
94 Fog Lamps
95 High-Beam Headlamps
96 -
97 -
98 -
99 -
100 O2 sensor A
101 Engine Control Module
102 Engine Control Module/ Transmission Control Module
103 Auxiliary Interior Heater
104 Starter
105 -
106 -
107 Aero Shutter
108 -
109 Police Upfitter
110 -
111 -
112 Starter Relay
113 -
114 Front Windshield Washer
115 Rear Window Washer
116 Cooling Fan Left
117 Fuel pump prime
118 -
119 -
120 Fuel pump prime
121 Right HID Headlamp
122 Left HID Headlamp
123 Cooling Fan Right





Luggage compartment fuse box:

Fuse/Relay N° Functions
1 Rear defogger relay
2 Left heated second row seat
3 Right heated second row sea
4 Heated Mirrors
5 Liftgate
6 Glass Breakage
7 Liftglass
8 Liftgate Module Logic
9 Rear Wiper
10 Rear Heater, Ventilation and Air Conditioning Blower
11 Second Row Seat
12 Liftgate Module
13 Third Row Seat
14 Rear Accessory Power Outlet
15 Rear Defogger
16 Liftgate
17 Liftglass
18 Rear Fog Lamp (if equipped)
19 Rear Fog Lamp (if equipped)
20 Heated Mirrors
