Cadillac CTS 2010 Fuse Box Info
Luggage compartment fuse box:
The luggage compartment fuse box is located on top of the battery, on the right side of the trunk.
Engine compartment fuse box:
Fuse Box Diagram | Layout
Luggage compartment fuse box:
| Fuse/Relay Name | Functions |
| FUEL/DR/ RELSE | Not Used |
| LCK | Lock |
| LT/POS/LP | Left Position Lamp |
| MRKR/LP | Not Used |
| REAR/FOG | Not Used |
| RT/POS/LP | Not Used |
| STOP/LP | Not Used |
| TRUNK/RELSE | Trunk Release |
| UNLCK | Unlock |
| AIRBAG | Airbag System |
| AMP | Amplifier |
| AUX/OUTLET | Auxiliary Power Outlet |
| CNSTR/VENT | Canister Vent |
| DR/LCK | Door Lock |
| ECM | Engine Control Module (ECM) |
| EE SEAT | Not Used |
| FUEL/PUMP | Fuel Pump |
| LT/POS/LP | Left Position Lamp |
| MSM | Memory Seat Module |
| ONSTAR | OnStar® System |
| PDM | Passenger Door Module |
| RDO | Audio System |
| RDO/SPKR | Audio Speakers |
| REAR/FOG | Not Used |
| RKE/ PASS-KEY/ MDL | Remote Keyless Entry System, Pass-Key Theft Deterrent Feature Module |
| RT/POS/LP | Not Used |
| RT/POS/LP | Right Position Lamp |
| RVC/SNSR | Regulated Voltage Control Sensor |
| S/ROOF | Sunroof |
| STOP/LP | Stoplamp |
| THEFT/UGDO | Theft Deterrent System, Universal Home Remote System |
| TRLR/ POS/LP | Not Used |
| TRUNK/RELSE | Trunk Release |
| DRV/ PWR/SEAT | Left Front Power Seat |
| LT/ REAR/ WNDW | Left Rear Window |
| PWR CLMN | Power Steering Column |
| PWR/WNDW | Power Window |
| PASS/ PWR/SEAT | Right Front Power Seat |
| REAR/WNDW | Right Rear Window |
Engine compartment fuse box:
| Fuse/Relay Name | Functions |
| A/C CLTCH | Air Conditioning Clutch |
| ABS | Antilock Braking System (ABS) |
| AFS | Adaptive Forward Lighting System |
| AIRBAG IGN | Airbag Switch |
| AQS/ ISRVM/ REAR CAMERA | Air Quality Sensor/ Inside Rear View Mirror/Rear View Camera |
| AWD | All-Wheel Drive |
| BCM 1 | Body Control Module 1 |
| BCM 2 | Body Control Module 2 |
| BCM 3 | Body Control Module 3 |
| BCM 4 | Body Control Module 4 |
| BCM 5 | Body Control Module 5 |
| SPARE | Spare |
| BCM 6, BCM 7 | Body Control Module 6 and 7 |
| DISPLY | Display |
| DRL/LT LO BEAM | Daytime Running Lamps/Left Low-Beam Headlamp |
| DRL RT | Right Daytime Running Lamp (DRL) |
| DRL/WSW | Daytime Running Lamps/Windshield Washer Pump |
| ECM | Engine Control Module (ECM) |
| ECM/TCM IGN | ECM, Transmission Control Module (TCM), Instrument Panel Cluster (IPC), PASS-Key III+ Module |
| EMIS 1 | Emission 1 |
| EMIS 2 | Emission 2 |
| EVEN COILS | Even Coils |
| FRT FOG | Front Fog Lamps |
| HDLP WASH | Not Used |
| HORN | Horn |
| LO BEAM DRL LEFT | Low-Beam Daytime Running Lamps (Left) |
| LT HI BEAM | Left High-Beam Headlamp |
| LT LO BEAM | Left Low-Beam Headlamp |
| LTR | Cigarette Lighter |
| MISC IGN | Ignition |
| NAV MTR | Navigation Motor |
| ODD COILS | Odd Coils |
| PED PRO | Not Used |
| PWR MODING | PassKey Module, Body Control Module |
| RT HI BEAM | Right High-Beam Headlamp |
| RT LO BEAM | Right Low-Beam Headlamp |
| RT LO BEAM | Right Low-Beam Headlamp |
| SPARE | Spare |
| SPARE | Spare |
| STR/WHL/ CNTRL | Steering Wheel Illumination |
| TCM BATT | Transmission Control Module Battery |
| TOSS/BRK VAC RLY | Transmission Output Speed Sensor/Brake Vacuum Relay |
| WPR | Windshield Wiper |
| SPARE | Spare |
| ABS MTR | ABS Motor |
| BLWR | Blower |
| BRK VAC PUMP | Brake Vacuum Pump |
| EPB | Not Used |
| FAN 1 | Cooling Fan 1 |
| FAN 2 | Cooling Fan 2 |
| REAR DEFOG | Rear Defogger |
| STRTR | Starter |
| SPARE | Spare |
| WSW/HTR | Windshield Washer Heater |
| A/C CMPRSR | Air Conditioning Compressor Clutch |
| DRL (W/O HID) LO BEAM (HID) | Daytime Running Lamps (without High Intensity Discharge), Low-Beam Headlamps (High Intensity Discharge) |
| FAN S/P | Cooling Fan Series/Parallel |
| FAN 1 | Cooling Fan 1 |
| FAN 2 | Cooling Fan 2 |
| FOG LAMP | Fog Lamps |
| HDLP WASH | Not Used |
| HI BEAM | High-Beam Headlamp |
| HORN | Horn |
| IGN 1 | Ignition 1 |
| LO BEAM (W/O HID) LT DRL (HID) | Low-Beam (without High Intensity Discharge), Left Daytime Running Lamp (High Intensity Discharge) |
| PWR/TRN | Powertrain |
| REAR DEFOG | Rear Defogger |
| RT DRL (HID) | Right Daytime Running Lamp (High Intensity Discharge) |
| SPARE | Spare |
| STRTR | Starter |
| WPR | Windshield Wiper |
| WPR HI | Windshield Wiper High Speed |
| WSW | Windshield Washer Pump |
