GEM e4 2021 Fuse Box

GEM e4 2021 Fuse Box Info



Engine compartment fuse box location:





Fuse Box Diagram | Layout



Engine compartment fuse box:

Fuse/Relay N° Rating Functions
MOTOR CONTROL RELAY - MOTOR CONTROL RELAY
DISPLAY RELAY - DISPLAY RELAY
CHASSIS RELAY - CHASSIS RELAY
VCM RELAY - VCM RELAY
DC/DC RELAY - DC/DC RELAY
BACKUP RELAY (OPT) - BACKUP RELAY (OPT)
HORN 10A HORN
INT. LIGHT 5A INT. LIGHT
DRIVE 5A DRIVE
WIPER 15A WIPER
CHASSIS 30A CHASSIS
ACC 15A ACC
VCM 20A VCM
DISPLAY 10A DISPLAY
CONSTANT 5A CONSTANT
LIGHTS 15A LIGHTS
