Vauxhall Viva 2017 Fuse Box Info
Passenger compartment fuse box location:
The instrument panel fuse box is located on the driver's side behind a cover in the instrument panel.
Engine compartment fuse box location:
Fuse Box Diagram | Layout
Passenger compartment fuse box:
| Fuse/Relay N° | Functions |
| 1 | Onstar |
| 2 | Air conditioning system |
| 3 | Instrument panel |
| 4 | Transmission control module |
| 5 | Infotainment |
| 6 | - |
| 7 | Rear parking assist |
| 8 | Data link connection |
| 9 | Electric steering column lock |
| 10 | Sensing and Diagnostic module |
| 11 | DC transformer |
| 12 | - |
| 13 | - |
| 14 | Linear power module |
| 15 | Central locking system/Ignition system |
| 16 | Ignition system |
| 17 | - |
| 18 | Instrument panel |
| 19 | - |
| 20 | Headlight range adjustment |
| 21 | Power windows, front |
| 22 | Power windows, rear |
| 23 | - |
| 24 | Manual transmission automated module |
| 25 | Auxiliary power outlet |
| 26 | Sunroof |
| 27 | - |
| 28 | Body control module 8 |
| 29 | Body control module 7 |
| 30 | Body control module 6 |
| 31 | Body control module 5 |
| 32 | Body control module 4 |
| 33 | Body control module 3 |
| 34 | Body control module 2 |
| 35 | Body control module 1 |
| 36 | - |
| 37 | Steering wheel control LED |
| 38 | - |
| 39 | Logistic/DC transformer |
| 40 | Power window, driver |
| 41 | Blower |
| 42 | Seat heating, front |
| 43 | Air conditioning module |
| 44 | Heated steering wheel |
| 45 | - |
Engine compartment fuse box:
| Fuse/Relay N° | Functions |
| 1 | Tailgate |
| 2 | - |
| 3 | Heated rear window |
| 4 | Heated exterior mirror |
| 5 | Sunroof |
| 6 | Transmission control module |
| 7 | Engine control module |
| 8 | - |
| 9 | ABS |
| 10 | Body control module, voltage |
| 11 | Rear view camera |
| 12 | - |
| 13 | - |
| 14 | Engine control module/Transmission control module |
| 15 | Injection system/Starter |
| 16 | Fuel pump |
| 17 | Engine control module1 |
| 18 | Engine control module2 |
| 19 | Injection system/Ignition |
| 20 | Air conditioning system |
| 21 | Battery sensor |
| 22 | Electric steering column lock |
| 23 | Cooling fan low |
| 24 | - |
| 25 | Exterior mirror switch |
| 26 | Engine control module/Manual transmission automated module |
| 27 | Fuel system |
| 28 | Brake switch |
| 29 | Seat occupancy recognition |
| 30 | Headlight range adjustment |
| 31 | Horn |
| 32 | Front fog light |
| 33 | High beam left |
| 34 | High beam right |
| 35 | - |
| 36 | Rear wiper |
| 37 | Cornering light left |
| 38 | Washer system |
| 39 | Cornering light right |
| 40 | - |
| 41 | - |
| 42 | Starter 2 |
| 43 | Instrument panel |
| 44 | Manual transmission automated, DC-DC converter |
| 45 | Starter 1 |
| 46 | ABS |
| 47 | Cooling fan high |
| 48 | Front wiper |
| 49 | Body control module/Retained power off |
