Suzuki Swift 2016 Fuse Box Info
Passenger compartment fuse box location:
The interior fuse box is under the dashboard on the driver’s side.
Engine compartment fuse box location:
Fuse Box Diagram | Layout
Passenger compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| 1 | 30A | - |
| 2 | 20A | - |
| 3 | 20A | STL |
| 4 | 20A | Rear defogger |
| 5 | 20A | - |
| 6 | 15A | - |
| 7 | 10A | - |
| 8 | 7.5A | Starting Signal |
| 9 | 15A | Accessory socket |
| 10 | 30A | Power window |
| 11 | 10A | Hazard |
| 12 | 7.5A | BCM |
| 13 | 15A | Ignition coil |
| 14 | 10A | ABS control module |
| 15 | 15A | Accessory |
| 16 | 10A | - |
| 17 | 15A | Horn |
| 18 | 10A | Stop light |
| 19 | 10A | Air bag |
| 20 | 10A | Back-up light |
| 21 | 15A | Wiper / Washer |
| 22 | 25A | Front wiper |
| 23 | 7.5A | Dome light |
| 24 | - | Blank |
| 25 | 7.5A | - |
| 26 | - | Blank |
| 27 | 7.5A | Ignition-1 signal |
| 28 | 15A | - |
| 29 | 10A | - |
| 30 | 15A | Radio |
| 31 | 10A | Tail lamp |
| 32 | 20A | D/L |
| 33 | 7.5A | - |
| 34 | 10A | Meter |
| 35 | 7.5A | Ignition-2 signal |
| 36 | 20A | - |
Engine compartment fuse box (Main fuses on battery/Fuse box):
| Fuse/Relay N° | Rating | Functions |
| 1 | 80A | FL5 |
| 2 | 50A | FL4 |
| 3 | 100A | FL3 |
| 4 | 100A | FL2 |
| 5 | 100A | FL1 |
| 6 | 50A | Ignition switch -2 |
| 7 | - | Blank |
| 8 | 15A | CVT relay |
| 9 | - | Blank |
| 10 | 10A | Air compressor |
| 11 | 15A | FI |
| 12 | - | Blank |
| 13 | 60A | Power steering |
| 14 | 30A | Radiator fan |
| 15 | - | Blank |
| 16 | 30A | Blower fan |
| 17 | 30A | Starting motor |
| 18 | 40A | ABS motor |
| 19 | 30A | Accessory |
| 20 | - | Blank |
| 21 | 25A | Head light |
| 22 | 25A | ABS control module |
| 23 | - | Blank |
| 24 | 20A | Front fog light |
| 25 | - | Blank |
| 26 | 40A | Ignition switch |
| 27 | 7.5A | Starting Signal |
| 28 | 15A | Headlight (Left) |
| 29 | 15A | Headlight (Right) |
| 30 | - | Blank |
| 31 | - | Blank |
