Mazda 626 2001 Fuse Box Info
Passenger compartment fuse box location:
The fuse box is located below the instrument panel in front of the driver’s door.
Engine compartment fuse box location:
Fuse Box Diagram | Layout
Passenger compartment fuse box:
| Fuse/Relay N° and Name | Rating | Functions |
| 1. AUDIO | 15A | Audio system |
| 2. ROOM | 15A | Interior lights, Trunk light |
| 3. S. ROOF | 15A | Sunroof |
| 4. METER | 10A | Gauges, Back-up lights |
| 5. D. LOCK | 30A | Power door lock |
| 6. HAZARD | 15A | Hazard warning lights |
| 7. A/B&ABS | 10A | Air bag system, Antilock brake system |
| 8. - | - | - |
| 9. A/C | 10A | Air conditioner |
| 10. - | - | - |
| 11. TURN | 10A | Turn signals |
| 12. WIPER | 20A | Windshield wipers and washer |
| 13. P. WIND | 30A | Power windows |
| 14. - | - | - |
| 15. RADIO | 15A | Audio system, Socket, outside mirror |
| 16. ENGINE | 10A | Engine control system |
| 17. ILLUMI | 10A | Tail light, License plate lights, parking lights, Dashboard illumination |
| 18. STOP | 15A | Brake lights, Horn, Cruise control |
| 19. CIGAR | 15A | Accessory socket, clock, radio, outside mirror |
| 20. - | - | - |
| 21. - | - | - |
| 22. P. SEAT | 30A | Power seat |
| 23. M. DEF | 15A | Mirror defroter |
| 24. P. POINT | 15A | Power point |
Engine compartment fuse box:
| Fuse/Relay N° and Name | Rating | Functions |
| 1. EGI INJ | 30A | Fuel-injection system |
| 2. DEFOG | 40A | Rear window defroster |
| 3. - | - | - |
| 4. MAIN | 100A | For protection of all circuits |
| 5. IG KEY | 30A | RADIO, SUNROOF, TURN, METER, ENGINE, POWER WINDOW, WIPER fuses, Ignition system |
| 6. HEATER | 40A | Heater, Air conditioner |
| 7. BTN | 40A | TAIL, STOP, ROOM, DOOR LOCK, HAZARD, POWER SEAT fuses |
| 8. COOLING FAN | 30A | Cooling fan |
| 9. AD FAN | 30A | Additional fan |
| 10. (ABS) | 60A | Antilock brake system |
| 11. TAIL | 15A | Tail lights, Parking lights, Dashboard illumination, License plate lights, Switches illumination |
| 12. HORN | 15A | Horn |
| 13. (ABS) | 20A | Antilock brake system |
| 14. - | - | - |
| 15. ST. SIGN | 10A | Starter signal |
| 16. H/L–L | 15A | Head light (Left) |
| 17. H/L–R | 15A | Head light (Right) |
| 18. (ABS) | 20A | Antilock brake system |
