Mazda CX-9 2014 Fuse Box Info
Fuse box location:
The fuse box is located behind the glove box.
Engine compartment fuse box:
Fuse arrangement in engine compartment.
Fuse Box Diagram | Layout
Passenger compartment fuse box:
| Fuse | Rating | Functions |
| 1. OUTLET FR | 15A | Accessory Socket (Front) |
| 2. MIRROR | 7.5A | Power control mirror |
| 3. C/U-IG1 | 15A | For protection of various circuits |
| 4. METER | 10A | Instrument cluster |
| 5. SAS | 7.5A | ABS, Air bag |
| 6. ENG.IGA | 7.5A | Engine control system |
| 7. STA | 7.5A | Engine control system |
| 8. - | - | - |
| 9. A/C | 7.5A | Air conditioner |
| 10. R.WIPER | 15A | Rear window wiper |
| 11. - | - | - |
| 12. P.LIFT GATE | 20A | Power lift gate* |
| 13. SUNROOF | 15A | Moonroof* |
| 14. AUDIO | 10A | Audio system |
| 15. M.DEF | 10A | Mirror defroster* |
| 16. P/W | 25A | Power windows (Passenger-side) |
| 17. TAIL | 10A | Taillights, Parking lights, License plate lights, Side-marker lights |
| 18. ILLUMI | 10A | Instrument panel illumination |
| 19. INJ | 7.5A | Engine control system |
| 20. - | - | - |
| 21. OUTLET CTR | - | - |
| 22. OUTLET RR | - | - |
| 23. WIPER | 30A | Windshield wiper and washer |
| 24. P.WIND | 30A | Power windows (Driver-side) |
*Some models
Engine compartment fuse box:
| Fuse | Rating | Functions |
| 1. MAIN | 150A | For protection of all circuits |
| 2. - | - | - |
| 3. ENGINE | 20A | Engine control system |
|
4. H/L R*1 4. H/L HI RY*2 |
15A 15A |
Headlight (RH) For protection of various circuits* |
| 5. R HEATER | 40A | Heater |
| 6. P.SEAT R | 30A | Power seat (RH)* |
| 7. HEATER | 50A | Heater |
| 8. IGKEY 2 | 40A | For protection of various circuits |
| 9. FAN 1 |
30A* 40A* |
Cooling fan |
| 10. P.SEAT L | 40A | Power seat (LH)* |
| 11. DEFOG | 30A | Rear window defroster |
| 12. BTN | 50A | For protection of various circuits |
| 13. FUEL PUMP | 30A | Fuel pump |
| 14. IGKEY 1 | 30A | For protection of various circuits |
| 15. FOG | 15A | Fog lights* |
| 16. ABS (SOL) | 30A | ABS |
| 17. D/L | 25A | Power door locks |
| 18. ROOM | 15A | Overhead light |
| 19. OUTLET CTR | 15A | Accessory socket (Center) |
| 20. OUTLET RR | 15A | Accessory socket (Rear) |
| 21. AC PWR | 15A | Moonroof*, DC/AC inverter* |
| 22. S.WARM | 15A | Seat warmer* |
| 23. A/C MAG | 10A | Air conditioner |
| 24. BOSE | 25A | Audio system (Bose® Sound System-equipped model)* |
| 25. FAN 2 |
30A* 40A* |
Cooling fan |
| 26. ABS | 50A | ABS |
| 27. IG COIL | 25A | Engine control system |
|
28. H/L L*1 28. H/L LOW L*2 |
15A 15A |
Headlight (LH) Headlight low beam (LH) |
|
29. ―*1 29. H/L LOW R*2 |
- 15A |
- Headlight low beam (RH) |
|
30. ―*1 30. H/L HIGH*2 |
- 20A |
- Headlight high beam |
| 31. HAZARD | 15A | Hazard warning flashers, Turn signal lights |
| 32. ENG+B | 10A | Engine control system |
| 33. HORN | 10A | Horn |
| 34. STOP | 7.5A | Brake lights |
| 35. EGI INJ | 10A | Engine control system |
| 36. ENG BAR | 20A | Engine control system |
| 37. ENG BAR 2 | 7.5A | Engine control system |
*1 With xenon fusion headlights
*2 With halogen headlights
*Some models
Engine compartment relay box:
| Fuse | Rating | Functions |
| 1. INJ | 7.5A | Engine control system |
| 2. - | - | - |
| 3. - | - | - |
