Mazda CX-7 2007 Fuse Box Info
Passenger compartment fuse box location:
The fuse box is located at the left side of the steering column at the bottom of the instrument panel.
Engine compartment fuse box location:
Fuse Box Diagram | Layout
Passenger compartment fuse box:
| Fuse/Relay N° Name | Rating | Functions |
| 1. OUTLET 1 | 15A | Accessory Socket |
| 2. OUTLET 2 | 15A | Accessory Socket |
| 3. P.MIR | 7.5A | Power control mirror |
| 4. WIPER | 30A | Windshield wiper and washer |
| 5. M.DEF | 7.5A | Mirror defroster* |
| 6. ENG BAR 3 | 7.5A | Air flow sensor, EGR control valve |
| 7. P.WIND | 15A | Power windows |
| 8. A/B | 7.5A | Advance Restraint System |
| 9. ENGINE | 15A | Engine control system |
| 10. METER | 10A | Instrument cluster |
| 11. ROOM | 15A | Audio system, Overhead light |
| 12. ILLUMI | 10A | Dashboard illumination |
| 13. SEAT | 20A | Seat warmer* |
| 14. A/C | 10A | Air conditioner* |
| 15. R.WIP | 10A | Rear window wiper and washer |
* Some models
Engine compartment fuse boxes:
| Fuse/Relay N° Name | Rating | Functions |
| 1. IGN 2 | 40A | Ignition system |
| 2. BLOWER | 40A | Blower motor |
| 3. BTN | 60A | For protection of various circuits |
| 4. FAN 2 | 40A | Cooling fan |
| 5. IGN 1 | 40A | Ignition system |
| 6. FAN 1 | 40A | Cooling fan |
| 7. P.SEAT | 40A | Power seat* |
| 8. INJ | 30A | Injector |
| 9. ROOF | 20A | Moonroof* |
| 10. BOSE | 30A | Bose audio system* |
| 11. ENGINE | 30A | Engine control system |
| 12. D.LOCK | 20A | Power door locks |
| 13. P.WIND | 30A | Power windows |
| 14. FUEL | 30A | Fuel pump |
| 15. ABS 1 | 40A | ABS |
| 16. ABS 2 | 20A | ABS |
| 17. DSC | 7.5A | DSC |
| 18. FOG | 20A | Fog lights* |
| 19. DEF | 30A | Rear window defroster |
| 20. TNS | 15A | Parking lights, License plate lights, Illuminated entry system |
| 21. A/C | 10A | Air conditioner* |
| 22. ETC | 20A | Accelerator position sensor |
| 23. H/L HI | 15A | Headlight leveling* |
| 24. DRL | 15A | DRL* |
| 25. H/L LO RH | 15A | Headlight low beam (RH) |
| 26. H/L LO LH | 15A | Headlight low beam (LH) |
| 27. ENG BAR 2 | 7.5A | PCM |
| 28. ECM | 10A | Engine control system |
| 29. ENG BAR 1 | 15A | Air flow sensor, EGR control valve |
| 30. P.WIND 2 | 20A | Power windows |
| 31. STOP | 10A | Brake lights |
| 32. HORN | 20A | Horn |
| 33. ENG B+ | 25A | PCM |
| 34. HAZARD | 10A | Hazard warning flashers, Turn signals |
* Some models
