Mazda5 2012 Fuse Box Info
Passenger compartment fuse box location:
The fuse box is located on the right hand side of the instrument panel facing the passenger’s side door.
Engine compartment fuse box location:
Fuse Box Diagram | Layout
Passenger compartment fuse box:
| Fuse/Relay N° Name | Rating | Functions |
| 1. P/W | 30A | Power window |
| 2. M.DEF | - | - |
| 3. STARTER | 10A | Engine control system |
| 4. ENG3 | 20A | Engine control system |
| 5. P/W | - | - |
| 6. P.OUTLET | 15A | Accessory sockets (Cargo compartment) |
| 7. SHIFT/L | 5A | - |
| 8. CIGAR | 15A | Accessory sockets (Dashboard) |
| 9. MIRROR | 7.5A | Power control mirror |
| 10. A/C | 10A | Air conditioner |
| 11. F.WIP | 25A | Windshield wipers and washer |
| 12. R.WIP | 15A | Rear window wiper |
| 13. ENG | - | - |
| 14. METER | 10A | Instrument cluster |
| 15. SAS | 10A | Air bag |
| 16. S.WARM | 15A | Seat warmer* |
| 17. ABS/DSC | - | - |
| 18. EHPAS | 5A | Power assist steering |
| 19. ENG2 | 15A | Engine control system |
* Some models
Engine compartment fuse boxes:
| Fuse/Relay N° Name | Rating | Functions |
| 1. IG KEY1 | 50A | For protection of various circuits |
| 2. AD FAN | 30A | Cooling fan |
| 3. GLOW2 HEATER2 | 30A | Air conditioner |
| 4. EGI MAIN | 40A | Engine control system |
| 5. INJ FAN2 | - | - |
| 6. ABS P | 40A | ABS, DSC |
| 7. P.SLIDE L | - | - |
| 8. TCM | 20A | Transaxle control system* |
| 9. HEATER1 | 40A | Air conditioner |
| 10. GLOW1 HEATER3 | 30A | Air conditioner |
| 11. BTN | 60A | For protection of various circuits |
| 12. IG KEY2 | 40A | For protection of various circuits |
| 13. FAN1 | 30A | Cooling fan |
| 14. P.SLIDE R | - | - |
| 15. EHPAS | 80A | Power assist steering |
| 16. FOG | 15A | Fog lights* |
| 17. D.LOCK | 20A | Power door lock |
| 18. P.WIND | 20A | Power window |
| 19. AT PUMP | - | - |
| 20. HEAD HI | 20A | Headlight high beam |
| 21. ENG+B | 10A | Engine control system |
| 22. STOP | 10A | Brake lights |
| 23. F.WARMER FUEL PUMP | 20A | Fuel pump |
| 24. HAZARD | 10A | Hazard warning flasher, Turn signal lights |
| 25. ROOM | 15A | Overhead lights |
| 26. TAIL | 15A | Taillights, Parking lights, License plate lights |
| 27. A/C MAG | 10A | Air conditioner |
| 28. ABS V | 20A | ABS, DSC |
| 29. SUN ROOF | 20A | Moonroof* |
| 30. H/CLEAN | - | - |
| 31. HORN | 15A | Horn |
| 32. - | - | - |
| 33. ILLUMI | 7.5A | Illumination |
| 34. ENG INJ | 25A | Engine control system |
| 35. ENG BAR | 15A | Engine control system |
| 36. - | - | - |
| 37. M.DEF | 7.5A | Mirror defroster* |
| 38. DEFOG | 25A | Rear window defroster |
| 39. HEAD LO L | 15A | Headlight low beam (LH) |
| 40. HEAD LO R | 15A | Headlight low beam (RH) |
* Some models
