Mazda5 2007 Fuse Box Info
Passenger compartment fuse box location:
The fuse box is located on the right hand side of the instrument panel facing the passenger’s side door.
Engine compartment fuse box location:
Fuse Box Diagram | Layout
Passenger compartment fuse box:
| Fuse/Relay N° Name | Rating | Functions |
| 1. M.DEF | 7.5A | Mirror defroster* |
| 2. - | - | - |
| 3. - | - | - |
| 4. P.OUTLET | 15A | Accessory Socket |
| 5. SHIFT/L | 5A | AT shift* |
| 6. CIGAR | 15A | Accessory Socket |
| 7. MIRROR | 7.5A | Power control mirror, Audio system* |
| 8. A/C | 10A | Air conditioner |
| 9. F.WIP | 25A | Windshield wipers and washer |
| 10. R.WIP | 15A | Rear window wiper and washer |
| 11. ENG | 5A | PCM |
| 12. METER | 10A | Instrument cluster |
| 13. SAS | 10A | Supplemental restraint systems |
| 14. S.WARM | 15A | Seat warmer* |
| 15. ABS/DSC | 5A | ABS |
| 16. EHPAS | 5A | EHPAS |
| 17. ENG2 | 15A | O2 heater |
| 18. P/W | 30A | Power windows* |
| 19. P/W | 40A | - |
* Some models
Engine compartment fuse boxes:
| Fuse/Relay N° Name | Rating | Functions |
| 1. FAN | 30A | Cooling fan |
| 2. FAN | 30A | Cooling fan |
| 3. P.WIND | 40A | - |
| 4. IG KEY1 | 30A | - |
| 5. ABS-V | 20A | ABS |
| 6. ABS-P | 30A | ABS |
| 7. IG KEY2 | 20A | For protection of various circuits |
| 8. HEATER DEICER | 20A | - |
| 9. BLOWER | 40A | Blower motor |
| 10. GLOW IG KEY1 | 40A | For protection of various circuits |
| 11. BTN | 40A | For protection of various circuits |
| 12. IG KEY2 | 40A | - |
| 13. CLOSER P.SLIDE LH | 20A | Easy closer (LH)* |
| 14. CLOSER P.SLIDE RH | 20A | Easy closer (RH)* |
| 15. EHPAS | 80A | EHPAS |
| 16. FOG | 15A | Front fog lights* |
| 17. D.LOCK | 20A | Power door lock |
| 18. P.WIND H/CLEAN | 20A | - |
| 19. MAG | 10A | Magnet clutch |
| 20. DEFOG | 25A | Rear window defroster |
| 21. ENG+B | 10A | PCM |
| 22. STOP | 10A | Brake lights |
| 23. FUEL | 20A | Fuel pump |
| 24. HAZARD | 10A | Turn signals, Hazard warning flashers |
| 25. ROOM | 15A | Overhead lights, Map lights, Luggage compartment light, For protection of various circuits |
| 26. - | - | - |
| 27. - | - | - |
| 28. GLOW SIG | 7.5A | - |
| 29. HEAD HR | 10A | Headlight high beams (RH) |
| 30. HEAD HL | 10A | Headlight high beams (LH) |
| 31. HORN | 15A | Horn |
| 32. SUN ROOF | 20A | Sunroof* |
| 33. ETC MIRROR BURGLAR | 7.5A | PCM |
| 34. HEAD LR | 15A | Headlight low beams (RH), Manual Headlight leveling* |
| 35. HEAD LL | 15A | Headlight low beams (LH) |
| 36. ENG BAR2 | 15A | O2 heater* |
| 37. ENG BAR | 15A | PCM |
| 38. INJ | 20A | Injector |
| 39. ILLUMI | 10A | Illumination |
| 40. TAIL | 10A | Taillights, Parking lights, License plate lights, For protection of various circuits |
* Some models
