Mazda Tribute 2004 Fuse Box Info
Passenger compartment fuse box location:
The fuse box is located below and to the left of the steering wheel by the brake pedal.
Engine compartment fuse box location:
Fuse Box Diagram | Layout
Passenger compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| 1 | 5A | Canister Vent Control Solenoid |
| 2 | 5A | Blower relay (coil), Pressure switch to PCM |
| 3 | 10A | Rear wiper motor, Rear washer motor, Rear wiper relay (coil) |
| 4 | 10A | Four-wheel drive control module, Cluster (restraints control warning) |
| 5 | 5A | ABS unit (EVAC & FILL), ASC unit, Restraints Control Module (RCM), ASC main SW to ASC unit, Clock spring switch |
| 6 | 10A | Flasher unit, Reversing lamps, Park Aid Module (PAM) |
| 7 | 10A | Passive Anti-theft Transceiver (PATS), RCM, EEC fuse |
| 8 | 10A | Cluster, Shift lock relay (coil), O/D signal to PCM, GEM, E/C autolamp mirror |
| 9 | 3A | PCM relay (coil), Fan relay 1, 2, 3 (coil), A/C relay (coil) |
| 10 | 20A | Front wiper motor, Front washer motor |
| 11 | 10A | ACC relay (coil), Key interlock solenoid, GEM |
| 12 | 5A | Radio |
| 13 | - | Not Used |
| 14 | 20A | Cigar Lighter |
| 15 | 15A | Park lamp relay, Front position lamps, License lamps, Tail lamps, Park lamp relay (coil), Trailer fuse, Illumination fuse |
| 16 | 10A | Cluster, Power mirror, GEM, Heated seats |
| 17 | 15A | Sun Roof Motor |
| 18 | 5A | Illumination for: Cluster, Heater unit, Radio, Hazard switch, Rear defrost switch, 4WD switch, Front fog switch |
| 19 | 10A | Subwoofer Amp |
| 20 | 15A | Turn Indicators, Front Side Turn Lamps, Front turn lamps, Rear turn lamps, Trailer turn, Flasher unit |
| 21 | 10A | Trailer position lamps |
| 22 | 15A | Not Used |
| 23 | 20A | Horn relay |
| 24 | 15A | Stoplamps, High mounted stoplamp, Trailer stoplamp, ABS unit, ASC unit (Brake Pedal Position Switch), PCM, Shift solenoid |
| 25 | 30A | Power window motors |
| 26 | 30A | Power door lock motors, GEM (door lock relay coil), Power seat, 4WD relay |
| 27 | 10A | GEM, Audio, Cluster, Interior lamp, Map lamp, Cargo lamp, Datalink connector |
| ACC | - | Accessory Relay |
Engine compartment fuse box:
| Fuse/Relay Name | Rating | Functions |
| Horn | 15A | Horn |
| H/L LH | 15A | Headlamp (High/Low Left, High Beams) |
| H/L RH | 15A | Headlamp (High/Low Right,, High Beams) |
| EEC | 5A | EEC (KPWR) |
| HEGO | 15A | HEGO 1,2, CMS 1,2, VMV |
| FUEL | 20A | Fuel Pump, EEC (FPM) |
| DIODE | - | - |
| DIODE | - | - |
| H/L RELAY MICRO | - | Headlamp (High/Low, Right/Left Relay) |
| HTD SEATS | 30A | Heated seats (if equipped) |
| INJ | 30A | EEC (VPWR), EVR, MAF, IAC, Bulkhead, HEGO fuse |
| MAIN | 120A | Main |
| ALT | 15A | Alternator/ Regulator |
| (DRL) | 15A | Daytime Running Lamps (DRL) unit (feed), DRL relay |
|
(DRL2) (HELV) |
15A (DRL2) 10A (HLEV) |
DRL module, HLEV |
| PWR 1 | 15A | Auxiliary Power Point |
| FOG | 20A | Foglamps, Foglamp indicator |
| A/C | 15A | A/C Clutch |
| (ABS) | 25A | Anti-Lock Brake System (ABS) SOL, EVAC & FILL |
| PWR 2 | 15A | Auxiliary Power Point |
| IG MAIN | 40A | Starter |
| HTR | 40A | Blower Motor, Blower Motor Relay |
| BTN 1 | 40A | JB - Accessory relay, Radio, TNS relay, Cigar lighter, Cluster, Power mirror, GEM, Accessory delay relay, Power windows, Power moonroof |
| (ABS) | 60A | ABS motor, EVAC & FILL |
| BTN 2 | 40A | JB - Radio, CD changer, Cluster, Dome lamps, Map lamps, Cargo lamps, Horn relay, GEM, Power locks, Speed control |
| MAIN FAN |
40A (2.0L) 50A (3.0L) |
Main Fan |
| R DEF | 30A | Rear Defroster |
| ADD FAN |
40A (2.0L) 50A (3.0L) |
Add Fan |
| EEC MAIN ISO | - | EEC Relay |
| FUEL PUMP ISO | - | Fuel Pump Relay |
| MAIN FAN ISO | - | Low-speed fan control relay (2.0L engine) High-speed fan control relay 1 (3.0L engine) |
| ADD FAN ISO | - | High-speed fan control relay 1 (2.0L engine) Low-speed fan control relay (3.0L engine) |
| DEF RELAY ISO | - | Rear Defroster Relay |
| ST RELAY ISO | - | Starter Relay |
| ADD FAN 2 ISO | - | High-speed fan control relay 2 (3.0L engine) Medium-speed fan control relay (2.0L engine) |
| FOG RELAY MICRO | - | Foglamp Relay |
| A/C RELAY MICRO | - | A/C Clutch Relay |
