Ford E-450 1997 Fuse Box Info
Passenger compartment fuse box location:
The fuse box is located below and to the left of the steering wheel by the brake pedal.
Engine compartment fuse box location:
The power distribution box is located in the engine compartment.
Fuse Box Diagram | Layout
Passenger compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| 1 | 20A | 4WABS or RABS module |
| 2 | 15A | 4WABS relay (coil), RABS (diode/resistor), instrument cluster, warning chime |
| 3 | 15A | Headlamp switch, radio sense, rear radio control, Remote keyless entry module |
| 4 | 15A | Power mirrors, modified vehicle, power locks w/RKE, Headlamp switch (dome), illuminated entry, Courtesy lamp switches, Radio (KAP), Cluster (KAP), warning chime |
| 5 | 20A | Remote keyless entry module, power door lock switches, memory lock |
| 6 | 10A | Brake shift interlock, speed control, daytime running light module |
| 7 | 10A | Multi-function switch |
| 8 | 30A | Noise supression capacitor, ignition coil positive feed, PCM relay diode/PCM power relay, fuel heater (diesel), glow plug relay (diesel) |
| 9 | 30A | Wiper control module, wiper motor |
| 10 | 20A | Headlamp switch (exterior lamps), Multi-function switch (flash-to-pass) |
| 11 | 15A | Stoplight switch, brake pressure switch, multi-function switch |
| 12 | 15A | Digital transmission range sensor (backup lamps), auxiliary battery relay |
| 13 | 15A | A/C mode switch, blend door actuator |
| 14 | 5A | Instrument cluster (air bag and charge indicator lamps) |
| 15 | 5A | Trailer tow battery charge relay (coil) |
| 16 | 30A | Power seats |
| 17 | - | Not used |
| 18 | - | Not used |
| 19 | 10A | Air bag module |
| 20 | 5A | Overdrive cancel switch |
| 21 | 30A | Power windows |
| 22 | - | Not used |
| 23 | 20A | Cigar lighter, data link connector |
| 24 | 5A | Illuminated entry |
| 25 | 10A | Left headlamp (low beam) |
| 26 | - | Not used |
| 27 | - | Not used |
| 28 | 25A | Instrument panel power point |
| 29 | - | Not used |
| 30 | 15A | Headlamps (high beam), Daytime running lamps (DRL), high beam indicator |
| 31 | 10A | Right headlamp (low beam), Daytime running lamps (DRL) |
| 32 | - | Not used |
| 33 | - | Not used |
| 34 | 10A | Digital transmission range sensor (start control) |
| 35 | - | Not used |
| 36 | 5A | Panel illumination |
| 37 | - | Not used |
| 38 | 10A | Air bag module |
| 39 | - | Not used |
| 40 | 30A | Modified vehicle |
| 41 | 30A | Modified vehicle |
| 42 | - | Not used |
| 43 | - | Not used |
| 44 | - | Not used |
Engine compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| 1 | - | Generator to battery |
| 2 | - | Not used |
| 3 | - | Not used |
| 4 | 5A | PCM keep alive memory |
| 5 | 10A | Right trailer turn signal |
| 6 | 10A | Left trailer turn signal |
| 7 | - | Not used |
| 8 | 60A | Instrument panel fuses |
| 9 | 30A | PCM power relay |
| 10 | 60A | Auxiliary battery |
| 11 | - | Not used |
| 12 | 60A | Misc |
| 13 | 50A | Blower motor relay |
| 14 | 30A | Trailer running lamps, trailer backup lamps |
| 15 | 40A | Headlamp switch |
| 16 | 50A | Auxiliary A/C, remote keyless entry module |
| 17 | 30A | Fuel pump relay (gasoline), injector driver module relay (diesel) |
| 18 | 60A | Modified vehicle power |
| 19 | 60A | Anti-lock brake system (4WABS) |
| 20 | 20A | Electric brake controller (trailer tow) |
| 21 | 50A | Modified vehicle power |
| 22 | 40A | Trailer battery charge (relay) |
| 23 | 60A | Ignition switch feed |
| 24 | - | Not used |
| 25 | - | Not used |
| 26 | 10A | Alternator (diesel) |
| 27 | 15A | Horn, daytime running lamp module |
| 28 | - | PCM diode |
| 29 | - | Not used |
| A | - | Not used |
| B | - | Not used |
| C | - | Trailer backup lamps |
| D | - | Trailer running lamps |
| E | - | Trailer battery charge relay |
| F | - | Not used |
| G | - | PCM |
| H | - | Blower motor |
| J | - | Horn |
| K | - | Fuel pump or IDM |
