Ford Ranger 2013 Fuse Box Info
Passenger compartment fuse box location:
The fuse box is behind the cover on the left side of the steering column.
Engine compartment fuse box location:
The power distribution box is located in the engine compartment. The power distribution box contains high-current fuses that protect your vehicle’s main electrical systems from overloads.
Fuse Box Diagram | Layout
Passenger compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| 56 | 20A | Fuel pump |
| 57 | - | Not used |
| 58 | - | Not used |
| 59 | 5A | Passive anti-theft system (PATS) |
| 60 | 10A | Interior lamp, driver’s door switch pack, mood lights, puddle lights, Automatic shifter, footwell lamp |
| 61 | - | Not used |
| 62 | 5A | Rain sensor module |
| 63 | 5A | Tachograph |
| 64 | - | Not used |
| 65 | - | Not used |
| 66 | 20A | Driver’s door lock, central double locking |
| 67 | 5A | Stop lamp switch |
| 68 | - | Not used |
| 69 | 5A | Instrument cluster, Integrated control module (ICP), Tracking and blocking module |
| 70 | 20A | Central locking |
| 71 | 5A | Air conditioning |
| 72 | 7.5A | Alarm horn |
| 73 | 5A | On-board diagnostics II |
| 74 | 20A | Main beam |
| 75 | 15A | Front fog lamps |
| 76 | 10A | Reversing lamp, rear view mirror |
| 77 | 20A | Washer pump |
| 78 | 5A | Ignition switch |
| 79 | 15A | Radio, multi-function display |
| 81 | 5A | Multi-function display, Hi audio, Brake Valve Closing (BVC) module |
| 82 | 20A | Interior motion sensor |
| 83 | 20A | Washer pump ground |
| 84 | 20A | Central locking ground double locking ground |
| 85 | 7.5A | Instrument cluster, Parking aid module, Rear view camera, Manual A/C, Rear view mirror, tracking and blocking module |
| 86 | 10A | Restraint system, Passenger air-bag deactivation indicator |
| 87 | 5A | Tachograph |
| 88 | - | Not used |
| 89 | - | Not used |
Engine compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| Fuses | ||
| 1 | 60A | Passenger compartment fuse box supply (battery) |
| 2 | 60A | Passenger compartment fuse box supply (battery) |
| 3 (Petrol) | 50A | Engine cooling fan |
| 3 (Diesel) | 60A | Glow plug control module |
| 4 | 40A | ABS module |
| 5 | 30A | Electric windows (front and rear) |
| 6 | 25A | Four wheel drive (4WD) motor ground |
| 7 | - | Not used |
| 8 | - | Not used |
| 9 | 20A | Electric seat |
| 10 | 25A | Electric windows (front) |
| 11 | 30A | Blower motor |
| 12 | 25A | Four wheel drive (4WD) motor power |
| 13 | 20A | Starter solenoid |
| 14 | 20A | Heated rear window |
| 15 (Petrol) | 10A | Flex-fuel pump |
| 15 (Diesel) | 15A | Vapouriser glow plug |
| 16 | 10A | A/C Clutch |
| 17 | 25A | Electric windows (front) |
| 18 | 25A | Windscreen wiper motor |
| 19 | 25A | Windscreen wiper motor ground |
| 20 | 20A | Cigar lighter |
| 21 | 15A | Horn |
| 22 | 15A | Fuel injectors or flex-fuel valve |
| 23 | 10A | Differential lock solenoid |
| 24 | 20A | Auxillary power socket (front console) |
| 25 | 15A | Ignition coils, Temperature and Mass Air Flow sensor, Glow plug module, Vacuum Control Valve (VCV), Electronic Vacuum Regulator Valve (EVRV) |
| 26 | 7.5A | Electronic control module (ECM) |
| 27 | 10A | Transmission control module (TCM) |
| 28 | 10A | Heated exhaust gas oxygen, Universal Heated Exhaust Gas Oxygen-sensor, Relay coils |
| 29 | 15A | Electronic control module (ECM) |
| 30 | 15A | Battery monitoring sensor |
| 31 | 20A | Auxillary power socket (rear console) |
| 32 | 5A | A/C pressure switch |
| 33 | 10A | Transmission control module (TCM) |
| 34 | 5A | PTC heater (where fitted) |
| 35 | 20A | Passenger compartment fuse box supply (Ignition) |
| 36 | 5A | ABS module |
| 37 | 10A | Headlamp levelling |
| 38 | 20A | Heated seat |
| 39 | 10A | Power mirrors |
| 40 | 10A | Vapouriser pump |
| 41 | 10A | Heated mirrors |
| 42 | 10A | Alarm horn |
| 43 | 30A | Heated windscreen (right) |
| 44 | 30A | Heated windscreen (left) |
| 45 | 25A | ABS module |
| 46 | 20A | Auxillary power socket (bedliner) |
| 47 | 40A | Trailer tow module |
| 48 | - | Not used |
| 49 | - | Not used |
| 50 | 5A | Ignition relay, Relay coils |
| 51 (Brazil only) | 30A | Electric windows (rear) |
| 51 | 20A | Trailer tow (12 or 13 pin battery feed, Permanent live) |
| Relays | ||
| 1 | - | Key interlock |
| 2 | - | Wiper on or off |
| 3 | - | Horn |
| 4 | - | A/C clutch |
| 5 | - | Differential lock |
| 6 | - | Wiper Hi or Lo |
| 7 | - | Engine cooling fan low |
| 8 | - | Engine cooling fan high |
| 9 | - | Flex-fuel pump, Vapouriser glow plug |
| 10 | - | Heated rear window |
| 11 | - | Heated windscreen |
| 12 | - | Not used |
| 13 | - | Electronic control module (ECM) power hold |
| 14 | - | Ignition |
| 15 | - | 4WD motor 2 (Clockwise) |
| 16 | - | 4WD motor 1 (Counter clockwise) |
| 17 | - | 4WD motor |
| 18 | - | Security horn |
| 19 | - | Starter motor |
| 20 | - | Not used |
| 21 | - | Not used |
| 22 | - | Not used |
| 23 | - | Not used |
| 24 | - | Not used |
| 25 | - | Not used |
| 26 | - | Blower motor |
| 27 | - | Electric seat |
