Abarth Punto Evo 2012 Fuse Box

Abarth Punto Evo 2012 Fuse Box Info



Passenger compartment fuse box location:

The fuse box is located at the left side of the steering column at the bottom of the instrument panel.



Engine compartment fuse box location:



Luggage compartment fuse box location:





Fuse Box Diagram | Layout



Passenger compartment fuse box:

Fuse/Relay N° Rating Functions
1 7.5A Right dipped headlamp
2 5A Courtesy light, boot light, glove compartment light
3 5A Instrument panel
4 20A Door locking/unlocking motors, dead lock activation motors, boot
unlocking motor
5 10A Supply and battery for EOBD diagnosis, automatic climate control unit, alarm, radio, Blue&Me™ control unit
6 20A Windscreen/rear window washer pump
7 20A Passenger side front electric window motor
8 7.5A Left dipped beam headlight, headlight alignment corrector
10 7.5A INT supply for brake pedal switch (NC contact), clutch pedal switch, interior heating unit, Blue&Me™ control unit, sound system wiring, voltage stabiliser control unit, reverse light on bumper, brake servo sensor, relay switch coils on engine compartment fusebox
11 5A INT supply for instrument panel, switch on brake pedal (NO contact), third brake light
12 5A INT supply for dashboard control lights, TMPS tyre pressure
measurement control unit, electric wing mirror movement,sunroof control unit, my-port infotelematic system socket, electrochromic rear view mirror
13 5A INT/A supply for switch coils on engine fuse box and relay switch coils on body computer control unit
14 20A Driver’s front electric window motor



Engine compartment fuse box:

Fuse/Relay N° Rating Functions
09 20A Hi-Fi sound system with radio, control unit and subwoofer
10 10A Horn
14 15A Left main beam headlamp, right main beam headlamp
19 7.5A Air climate control compressor
20 30A Heated rear window
21 15A Fuel pump on tank
30 15A Left fog light, right fog light
85 - Socket (set-up)
86 15A Passenger compartment socket, cigar lighter
87 5A Battery charge status sensor
88 7.5A Demister on driver-side door mirror, demister on passenger-side door mirror



Luggage compartment fuse box:

Fuse/Relay N° Rating Functions
01 - Free
02 - Free
03 - Free
04 - Free
05 15A Boot socket
06 - Free
07 - Free
08 - Free
09 - Free
13 5A TPMS (tyre pressure monitoring system) control unit
14 7.5A Alarm system management control unit
15 - Free
16 - Free
17 20A Sunroof opening system
