Fisker Ocean 2024 Fuse Box

Fisker Hits: 3497

Fisker Ocean 2024 Fuse Box Info

Passenger compartment fuse box location:

The fuse box located behind paneling in the instrument panel, to the left of the steering wheel.

Engine compartment fuse box location:

Luggage compartment fuse box location:

The fuse box is located behind paneling in the right side of the luggage compartment.

Fuse Box Diagram | Layout

Passenger compartment fuse box:

Fuse/Relay N°	Rating	Functions
RF01	30A	IGN1 Relay Control
RF02	30A	IGN2 Relay Control
RF04	10A	FCM/IP Switch/ETC
RF05	15A	VCU
RF06	15A	Left FDHAs
RF07	30A	BCM Interior Lamps
RF08	30A	BCM2
RF09	30A	BCM Exterior Lamps
RF10	30A	BCM Low/High 2
RF11	30A	BCM3
RF12	10A	DWSG
RF13	30A	BCM Low/High
RF14	20A	Left Rear Seat Switch
RF15	10A	ECC/HVAC/EXC_4WV
RF16	20A	CL30s Relay Control
RF17	5A	Relay Coil (Blower, Rear Defrost)/PKC/NFC Start
RF18	15A	PASC
RF19	10A	OBD/Alcohol Interlock
RF20	10A	RAC/RLS/TDS
RF21	5A	Front USB
RF22	15A	ICC/Tbox
RF23	10A	CID/Cluster
RF24	30A	Defrost Relay Control (Rear and Mirror)
RF26	7.5A	OHC
RF27	15A	Rear MCU
RF28	10A	CIM/GW
RF29	15A	Front MCU
RF30	5A	GW
RF31	5A	CIM/GW
RF32	10A	Front CMRRs/ACC Relay Feedback
RF33	10A	MRR/Rear CMRRs
RF34	10A	ACU
RF35	10A	Rear USB
RF36	15A	12V Trunk Outlet
RF37	10A	Mirror Heat
RF38	15A	CS/SWH
RF39	40A	Blower Relay Control
RF40	30A	AP_RL
RF43	30A	AP_FL
RF44	30A	AP_ML
RF54	10A	RAC/IP Switch/PWCs
RF55	5A	ICC/ECC/TBOX
RF56	7.5A	BCM/RVM/ETC
RF57	5A	VCU/CS/MFS/IGN2 Relay Feedback
RRY01	-	IGN1 Relay Control
RRY02	-	IGN2 Relay Control
RRY03	-	CL30s Relay Control
RRY04	-	Defrost Relay Control (Rear and Mirror)
RRY09	-	Blower Relay Control

Engine compartment fuse box A:

Fuse/Relay N°	Rating	Functions
EF01	60A	ESP1
EF02	40A	ESP2
EF03	40A	CFM
EF04	60A	EPS
EF05	40A	Amplifier Extreme
EF06	60A	EPS
EF07	20A	Front Defrost and Heated Washer Nozzle Relay
EF08	30A	EWM
EF09	15A	Front Defrost
EF10	10A	Heated Washer Nozzle
EF12	10A	AHL/FBMs
EF13	10A	Thermal Management System Relay
EF14	10A	Emergency Switch for EPS/ESP/iBooster
EF16	15A	Horn Relay
EF17	10A	Thermal Management System Relay
EF18	15A	Battery EWP Relay
EF19	15A	Heat EWP Relay
EF20	15A	Front Drive EWP Relay
EF22	15A	Rear Drive EWP Relay
EF23	5A	AGS
EF24	15A	SCM
EF25	5A	Emergency Switch for ESP/iBooster
EF26	10A	Rear First Responder Switch
EF28	10A	Siren
EF29	7.5A	Mini
EF30	15A	Battery Management System
EF32	5A	Brake Pedal Switch
EF33	5A	Front Defrost and Heated Washer Nozzle Relay/Horn Relay/VSP
EF35	15A	Washer Pump Relay
ERY01	-	Rear First Responder Switch
ERY03	-	Washer Pump
ERY04	-	Horn
ERY05	-	Thermal Management System
ERY06	-	Battery EWP
ERY07	-	Heat EWP
ERY08	-	Front Drive EWP
ERY09	-	Rear Drive EWP
ERY10	-	Front Defrost and Heated Washer Nozzle

Engine compartment fuse box B:

Fuse/Relay N°	Rating	Functions
MF01	125A	Rear Trunk Fusebox
MF02	60A	iBooster
MF03	150A	Power Unit Compartment Fusebox
MF04	175A	Passenger Compartment Fusebox
MF05	300A	PDU/DCDC
MF06	5A	IBS

Luggage compartment fuse box:
